LMV831 Series
Manufacturer: Texas Instruments
Beta
⌘K
BOARD EVAL FOR LMV831 3.3MHZ OA
| Part | Current - Output / Channel | Supplied Contents | Board Type | Current - Supply (Main IC) | Amplifier Type | Voltage - Supply (Single) Minimum | Supply Configuration | Voltage - Supply (Single) Maximum | Utilized IC / Part | Slew Rate | Contents | Gain Bandwidth Product | Channels per IC (Single) | Channels per IC (Type) | Channels per IC (Count) | Output Type | Package Name | Package / Case | Voltage - Supply Span (Max) | Mounting Type | Number of Circuits | Current - Supply | Operating Temperature (Max) | Operating Temperature (Min) | Voltage - Supply Span (Min) | Voltage - Input Offset | Current - Input Bias |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | 66 mA | Board(s) | Fully Populated | 0.00025 µA | General Purpose Standard (General Purpose) | 2.7 V | Dual Single | 5.5 V | LMV831 | 2 V/µs | Board | 3.3 MHz | 1 | Single | 1 | Single-Ended | |||||||||||
 Texas Instruments | 66 mA | General Purpose | 2 V/µs | 3.3 MHz | SC-70-5 | 5-TSSOP SC-70-5 SOT-353 | 5.5 V | Surface Mount | 1 | 250 µA | 125 °C | -40 °C | 2.7 V | 250 µV | 0.1 pA | ||||||||||||
 Texas Instruments | 66 mA | General Purpose | 2 V/µs | 3.3 MHz | SC-70-5 | 5-TSSOP SC-70-5 SOT-353 | 5.5 V | Surface Mount | 1 | 250 µA | 125 °C | -40 °C | 2.7 V | 250 µV | 0.1 pA |
