PCM6260 Series
Manufacturer: Texas Instruments
Beta
⌘K
AUTOMOTIVE 6-CH AUDIO ADC WITH INTEGRATED PROGRAMMABLE MIC BIAS, BOOST AND INPUT DIAGNOSTICS
| Part | Minimum Sampling Rate (Per Second) | Maximum Sampling Rate (Per Second) | Qualification | Resolution (Bits) | Package Length | Package Name | Package Width | Number of Channels | Package / Case | Type | Grade | Voltage - Supply (Range 1 Minimum) | Voltage - Supply (Range 2 Minimum) | Voltage - Supply (Range 1 Maximum) | Voltage - Supply (Range 2 Maximum) | Data Interface | Mounting Type | Operating Temperature (Max) | Operating Temperature (Min) | Voltage Supply Source |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | 8 kHz | 768 kHz | AEC-Q100 | 16 b 20 b 24 b 32 b | 5 mm | 32-WQFN | 5 mm | 6 | 32-WFQFN Exposed Pad | Audio | Automotive | 3 V | 1.65 V | 3.6 V | 1.95 V | I2C SPI | Surface Mount | 125 °C | -40 °C | Analog Digital |
