DAC8550 Series

Catalog

DAC8550 DAC EVALUATION BOARD LABVIEW IDE

Part	Supplied Contents	Settling Time	Number of DAC's	Data Interface	DAC Type	Utilized IC / Part	Contents	Number of Bits	Sampling Rate (Per Second)	Voltage - Supply, Digital (Min)	Voltage - Supply, Digital (Max)	Differential Output	Architecture	Mounting Type	Package Name	Reference Type	Output Type	Voltage - Supply, Analog (Min)	Voltage - Supply, Analog (Max)	Package Width	Package Length	DNL (LSB) Tolerance	INL (LSB) Tolerance	Operating Temperature (Min)	Operating Temperature (Max)	Number of D/A Converters
Texas Instruments DAC8550EVM	Board(s)	8 µs	1	DSP SPI	Voltage	DAC8550	Board	16 bits	1 MHz
Texas Instruments DAC8550IDGKTG4		10 µs		DSP SPI				16 bits		2.7 V	5.5 V	No	String DAC	Surface Mount	8-TSSOP 8-MSOP 8-VSSOP	External	Voltage - Buffered	2.7 V	5.5 V	3 mm	0.118 in	0.25 LSB	3 LSB	-40 °C	105 °C	1 count
Texas Instruments DAC8550IBDGKR		10 µs		DSP SPI				16 bits		2.7 V	5.5 V	No	String DAC	Surface Mount	8-TSSOP 8-MSOP 8-VSSOP	External	Voltage - Buffered	2.7 V	5.5 V	3 mm	0.118 in	0.25 LSB	3 LSB	-40 °C	105 °C	1 count
Texas Instruments DAC8550IBDGKTG4		10 µs		DSP SPI				16 bits		2.7 V	5.5 V	No	String DAC	Surface Mount	8-TSSOP 8-MSOP 8-VSSOP	External	Voltage - Buffered	2.7 V	5.5 V	3 mm	0.118 in	0.25 LSB	3 LSB	-40 °C	105 °C	1 count
Texas Instruments DAC8550IDGKR		10 µs		DSP SPI				16 bits		2.7 V	5.5 V	No	String DAC	Surface Mount	8-TSSOP 8-MSOP 8-VSSOP	External	Voltage - Buffered	2.7 V	5.5 V	3 mm	0.118 in	0.25 LSB	3 LSB	-40 °C	105 °C	1 count
Texas Instruments DAC8550IBDGKT		10 µs		DSP SPI				16 bits		2.7 V	5.5 V	No	String DAC	Surface Mount	8-TSSOP 8-MSOP 8-VSSOP	External	Voltage - Buffered	2.7 V	5.5 V	3 mm	0.118 in	0.25 LSB	3 LSB	-40 °C	105 °C	1 count
Texas Instruments DAC8550IDGKT		10 µs		DSP SPI				16 bits		2.7 V	5.5 V	No	String DAC	Surface Mount	8-TSSOP 8-MSOP 8-VSSOP	External	Voltage - Buffered	2.7 V	5.5 V	3 mm	0.118 in	0.25 LSB	3 LSB	-40 °C	105 °C	1 count
