LMG3100R044 Series
Manufacturer: Texas Instruments
Beta
⌘K
GATE DRIVERS 100V 4.4MOHM GAN FET WITH INTEGRATED DRI
| Part | Rds On (Typ) | Output Configuration | Input Type | Voltage - Supply (Vcc/Vdd) Maximum | Voltage - Supply (Vcc/Vdd) Minimum | Package / Case | Output Type | Operating Temperature (Max) | Operating Temperature (Min) | Output Ratio | Input Ratio | Number of Outputs | Package Name | Package Length | Package Width | Features | Switch Type | Current - Output (Max) | Fault Protection | Voltage - Load | Mounting Type |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
 Texas Instruments | 4.4 mOhm | Low Side | Non-Inverting | 5.25 V | 4.75 V | 15-QFN | N-Channel | 125 °C | -40 °C | 1 | 1 | 1 | 15-VQFN-FCRLF | 6.5 mm | 4 mm | Slew Rate Controlled | General Purpose | 46 A | UVLO | 100 V | Surface Mount |
