ADS8372 Series

Catalog

16-BIT 600KSPS SERIAL ADC WITH REF AND PSEUDO BIPOLAR, FULLY DIFFERENTIAL INPUT

Part	Voltage - Supply, Digital (Min)	Voltage - Supply, Digital (Max)	Data Interface	Number of A/D Converters	Input Type	Operating Temperature (Min)	Operating Temperature (Max)	Number of Bits	Number of Inputs	Sampling Rate (Per Second)	Voltage - Supply, Analog	Package / Case	Ratio - ADC	Ratio - S/H	Package Width	Package Name	Package Length	Architecture	Mounting Type	Configuration	Reference Type	Supplied Contents	Input Voltage (Min)	Input Voltage (Max)	Utilized IC / Part	Power (Typ)	Contents
Texas Instruments ADS8372IBRHPT	2.7 V	5.25 V	SPI	1 count	Differential Pseudo-Differential	-40 °C	85 °C	16 bits	1	600 kHz	5 V	28-VQFN Exposed Pad	1	1	6 mm	28-QFN	6 mm	SAR	Surface Mount	S/H-ADC	External Internal
Texas Instruments ADS8372IBRHPRG4	2.7 V	5.25 V	SPI	1 count	Differential Pseudo-Differential	-40 °C	85 °C	16 bits	1	600 kHz	5 V	28-VQFN Exposed Pad	1	1	6 mm	28-QFN	6 mm	SAR	Surface Mount	S/H-ADC	External Internal
Texas Instruments ADS8372IBRHPR	2.7 V	5.25 V	SPI	1 count	Differential Pseudo-Differential	-40 °C	85 °C	16 bits	1	600 kHz	5 V	28-VQFN Exposed Pad	1	1	6 mm	28-QFN	6 mm	SAR	Surface Mount	S/H-ADC	External Internal
Texas Instruments ADS8372IRHPT	2.7 V	5.25 V	SPI	1 count	Differential Pseudo-Differential	-40 °C	85 °C	16 bits	1	600 kHz	5 V	28-VQFN Exposed Pad	1	1	6 mm	28-QFN	6 mm	SAR	Surface Mount	S/H-ADC	External Internal
Texas Instruments ADS8372EVM			Serial	1 count				16 bits		600 kHz												Board(s)	0 mV	4.2 V	ADS8372	110 mW	Board
