ED-CM4SEN-1832-4C(US)

Active

EDATEC

SBC 1.5GHZ 4 CORE 8GB RAM

Search across all available documentation for this part.

Active

EDATEC

SBC 1.5GHZ 4 CORE 8GB RAM

Technical Specifications

Parameters and characteristics for this part

Specification	ED-CM4SEN-1832-4C(US)

Cooling Type	Heat Sink
Core Processor	Raspberry Pi CM4 # CM4108032: ARM Cortex-A72
Ethernet	10 Mbps, 1000 Mbps, 100 Mbps
Expansion Site/Bus	PCIe, mPCIe
Form Factor	Desktop
Number of Cores	4
Operating Temperature [Max]	60 °C
Operating Temperature [Min]	-25 °C
RS-232 (422, 485)	5
Size / Dimension [x]	103 mm
Size / Dimension [x]	4.055 in
Size / Dimension [y]	73 mm
Size / Dimension [y]	2.874 in
Speed	1.5 GHz
Storage Interface	eMMC
USB	micro USB Type-B (1), USB 2.0 Type-A (2)

Part	Form Factor	Core Processor	Storage Interface	USB	Number of Cores	RS-232 (422, 485)	Ethernet	Speed	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [x]	Expansion Site/Bus	Operating Temperature [Min]	Operating Temperature [Max]	Cooling Type
EDATEC ED-CM4SEN-1832-C	Desktop	Raspberry Pi CM4 # CM4108032: ARM Cortex-A72	eMMC	micro USB Type-B (1) USB 2.0 Type-A (2)	4	5	10 Mbps 100 Mbps 1000 Mbps	1.5 GHz	73 mm	103 mm	2.874 in	4.055 in	mPCIe PCIe	-25 °C	60 °C	Heat Sink
EDATEC ED-CM4SEN-1832-4C(US)	Desktop	Raspberry Pi CM4 # CM4108032: ARM Cortex-A72	eMMC	micro USB Type-B (1) USB 2.0 Type-A (2)	4	5	10 Mbps 100 Mbps 1000 Mbps	1.5 GHz	73 mm	103 mm	2.874 in	4.055 in	mPCIe PCIe	-25 °C	60 °C	Heat Sink

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Box	1	$ 266.93

General part information

Single Board Computer 1.5GHz 4 Core RAM Raspberry Pi CM4 # CM4108032: ARM Cortex-A72
