5502UE 008C500

Active

Belden Inc.

CABLE 4COND 22AWG GRAY 500'

Search across all available documentation for this part.

Active

Belden Inc.

CABLE 4COND 22AWG GRAY 500'

Technical Specifications

Parameters and characteristics for this part

Specification	5502UE 008C500

Cable Type	Multi-Conductor
Conductor Insulation	Polypropylene (PP)
Conductor Material	Copper, Bare
Conductor Strand [custom]	7
Conductor Strand [custom]	30 AWG
Features	Rip Cord
Jacket (Insulation) Diameter [diameter]	0.141 in
Jacket (Insulation) Diameter [diameter]	3.58 mm
Jacket (Insulation) Material	Poly-Vinyl Chloride (PVC), Riser
Jacket (Insulation) Thickness	0.432 mm
Jacket (Insulation) Thickness	0.017 in
Jacket Color	Gray
Length [x]	500 '
Length [x]	152.4 m
Number of Conductors	4
Ratings	UL Style CMR
Usage	Sound, Security
Voltage	300 V
Wire Gauge	22 AWG

Part	Ratings	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Length	Length	Wire Gauge	Conductor Insulation	Usage	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Cable Type	Features	Conductor Material	Conductor Strand [custom]	Conductor Strand [custom]	Voltage	Jacket (Insulation) Material	Number of Conductors	Jacket Color	Length [x]	Length [x]
Belden Inc. 5502UE 009U1000	UL Style CMR	0.432 mm	0.017 in	1000 ft	304.8 m	22 AWG	Polypropylene (PP)	Security Sound	0.141 in	3.58 mm	Multi-Conductor	Rip Cord	Copper Bare	7	30 AWG	300 V	Poly-Vinyl Chloride (PVC) Riser	4
Belden Inc. 5502UE 0091000	UL Style CMR	0.432 mm	0.017 in	1000 ft	304.8 m	22 AWG	Polypropylene (PP)	Security Sound	0.141 in	3.58 mm	Multi-Conductor	Rip Cord	Copper Bare	7	30 AWG	300 V	Poly-Vinyl Chloride (PVC) Riser	4
Belden Inc. 5502UE 0081000	UL Style CMR	0.432 mm	0.017 in	1000 ft	304.8 m	22 AWG	Polypropylene (PP)	Security Sound	0.141 in	3.58 mm	Multi-Conductor	Rip Cord	Copper Bare	7	30 AWG	300 V	Poly-Vinyl Chloride (PVC) Riser	4	Gray
Belden Inc. 5502UE 008U1000	UL Style CMR	0.432 mm	0.017 in	1000 ft	304.8 m	22 AWG	Polypropylene (PP)	Security Sound	0.141 in	3.58 mm	Multi-Conductor	Rip Cord	Copper Bare	7	30 AWG	300 V	Poly-Vinyl Chloride (PVC) Riser	4	Gray
Belden Inc. 5502UE 008C500	UL Style CMR	0.432 mm	0.017 in			22 AWG	Polypropylene (PP)	Security Sound	0.141 in	3.58 mm	Multi-Conductor	Rip Cord	Copper Bare	7	30 AWG	300 V	Poly-Vinyl Chloride (PVC) Riser	4	Gray	500 '	152.4 m

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

4 Conductor Multi-Conductor Cable Gray 22 AWG 500.0' (152.4m)
