30801 009250

Active

Belden Inc.

HOOK-UP STRND 1AWG WHITE

Search across all available documentation for this part.

Active

Belden Inc.

HOOK-UP STRND 1AWG WHITE

Technical Specifications

Parameters and characteristics for this part

Specification	30801 009250

Cable Type	Hook-Up
Conductor Material	Copper, Tinned
Conductor Strand [custom]	24 AWG
Conductor Strand [custom]	210 strands
Jacket (Insulation) Diameter [diameter]	0.622 in
Jacket (Insulation) Diameter [diameter]	15.8 mm
Jacket (Insulation) Material	Glass, Silicone
Jacket (Insulation) Thickness	2.03 mm
Jacket (Insulation) Thickness	0.08 in
Length	3000 "
Length	76.2 m
Operating Temperature [Max]	200 °C
Operating Temperature [Min]	-70 °C
Ratings	UL Style 3126
Voltage	600 V
Wire Gauge	1 AWG

Part	Jacket (Insulation) Thickness	Jacket (Insulation) Thickness	Cable Type	Voltage	Wire Gauge	Jacket (Insulation) Material	Jacket (Insulation) Diameter [diameter]	Jacket (Insulation) Diameter [diameter]	Operating Temperature [Max]	Operating Temperature [Min]	Ratings	Length	Length	Conductor Strand [custom]	Conductor Strand [custom]	Conductor Material	Length [x]	Length [x]	Jacket Color
Belden Inc. 30801 009250	2.03 mm	0.08 in	Hook-Up	600 V	1 AWG	Glass Silicone	0.622 in	15.8 mm	200 °C	-70 °C	UL Style 3126	3000 "	76.2 m	24 AWG	210 strands	Copper Tinned
Belden Inc. 30801 010100	2.03 mm	0.08 in	Hook-Up	600 V	1 AWG	Glass Silicone	0.622 in	15.8 mm	200 °C	-70 °C	UL Style 3126			24 AWG	210 strands	Copper Tinned	30.5 m	100 ft	Black

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Spool	250	$ 21.60

General part information

1 AWG Hook-Up Wire 210/24 White 600V 250.0' (76.2m)
