PEH200KB5100MB2

Active

KEMET

ELECTROLYTIC CAPACITOR, LONG LIFE, PEH200 SERIES, 10000 F, 20%, 40 V, 35 MM, 0.023 OHM ROHS COMPLIANT: YES

Search across all available documentation for this part.

Active

KEMET

ELECTROLYTIC CAPACITOR, LONG LIFE, PEH200 SERIES, 10000 F, 20%, 40 V, 35 MM, 0.023 OHM ROHS COMPLIANT: YES

Technical Specifications

Parameters and characteristics for this part

Specification	PEH200KB5100MB2

Applications	General Purpose
Capacitance	10000 µF
ESR (Equivalent Series Resistance)	23 mOhm
Height - Seated (Max)	60.5 mm
Height - Seated (Max) [Max] [z]	2.382 in
Impedance	18 mOhms
Lead Spacing	13 mm
Lead Spacing	0.512 in
Lifetime @ Temp.	10000 Hrs
Mounting Type	Chassis Mount
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	Radial, Can - Screw Terminals
Polarization	Polar
Ripple Current @ Low Frequency	12 A
Size / Dimension [diameter]	1.441 in
Size / Dimension [diameter]	36.6 mm
Tolerance	20 %
Voltage - Rated	40 V

Part	Capacitance	Height - Seated (Max) [Max]	Height - Seated (Max) [Max]	Package / Case	Tolerance	Lifetime @ Temp.	Lead Spacing	Lead Spacing	Impedance	Mounting Type	Polarization	ESR (Equivalent Series Resistance)	Size / Dimension [diameter]	Size / Dimension [diameter]	Voltage - Rated	Operating Temperature [Max]	Operating Temperature [Min]	Applications	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Ripple Current @ Low Frequency	Height - Seated (Max)
KEMET PEH200KO6100MB2	100000 µF	107 mm	4.213 in	Radial Can - Screw Terminals	20 %	15000 Hrs	1.122 in	28.5 mm	8 mOhms	Chassis Mount	Polar	8 mOhm	66.6 mm	2.622 in	40 V	85 °C	-40 °C	General Purpose
KEMET PEH200KJ5470MU2	47 mF			Radial Can - Screw Terminals	20 %	2000 Hrs	1.122 in	28.5 mm		Chassis Mount	Polar	8 mOhm	51.6 mm	2.031 in	40 V	85 °C	-40 °C	General Purpose	3.799 "	96.5 mm	22.1 A
KEMET PEH200KB5100MB2	10000 µF			Radial Can - Screw Terminals	20 %	10000 Hrs	0.512 in	13 mm	18 mOhms	Chassis Mount	Polar	23 mOhm	36.6 mm	1.441 in	40 V	85 °C	-40 °C	General Purpose		2.382 in	12 A	60.5 mm
KEMET PEH200KJ5470MB2	47 mF			Radial Can - Screw Terminals	20 %	12000 Hrs	1.122 in	28.5 mm		Chassis Mount	Polar	8 mOhm	51.6 mm	2.031 in	40 V	85 °C	-40 °C	General Purpose	3.76 in	95.5 mm	22.1 A

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

10000 µF 40 V Aluminum Electrolytic Capacitors Radial, Can - Screw Terminals 23mOhm @ 100Hz 10000 Hrs @ 85°C
