LCS100US12
XP POWER
AC/DC CONVERTER 12V 102W
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
LCS100US12
XP POWER
AC/DC CONVERTER 12V 102W
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | LCS100US12 |
|---|---|
| Applications | Household Appliances, ITE (Commercial), Industrial |
| Approval Agency | CE, TUV, UL |
| Efficiency | 87 % |
| Features | Adjustable Output, Universal Input |
| Minimum Load Required | False |
| Mounting Type | Chassis Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -30 °C |
| Power (Watts) | 102 W |
| Size / Dimension [x] | 129 mm |
| Size / Dimension [x] | 5.08 in |
| Size / Dimension [y] | 3.82 in |
| Size / Dimension [y] | 97 mm |
| Size / Dimension [z] | 30 mm |
| Size / Dimension [z] | 1.18 in |
| Standard Number | 62368-1 |
| Type | Enclosed |
| Voltage - Input [Max] | 264 VAC, 373 VDC |
| Voltage - Input [Min] | 85 VAC, 120 VDC |
| Voltage - Isolation | 4000 V |
| Voltage - Output 1 | 12 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 18.00 | |
Description
General part information
LCS100 Series
Enclosed AC DC Converters 1 Output 12V 85 ~ 264 VAC, 120 ~ 373 VDC Input
