YQ30NL10SDTL

Active

Rohm Semiconductor

TRENCH MOS STRUCTURE, 100V, 30A, LPDL, HIGHLY EFFICIENT SBD

Deep-Dive with AI

DocumentsImpedance Characteristics of Bypass Capacitor Power Loss and Thermal Design of Diodes +23

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics for this part

Specification	YQ30NL10SDTL

Current - Average Rectified (Io)	30 A
Current - Reverse Leakage @ Vr	95 µA
Mounting Type	Surface Mount
Operating Temperature - Junction	150 ¯C
Package / Case	D2PAK (2 Leads + Tab), TO-263AB, TO-263-3
Speed	200 mA, 500 ns
Supplier Device Package	TO-263L
Technology	Schottky
Voltage - DC Reverse (Vr) (Max) [Max]	100 V
Voltage - Forward (Vf) (Max) @ If	990 mV

YQ30NL10SD Series

Trench MOS Structure, 100V, 30A, LPDL, Highly Efficient SBD

Part	Technology	Current - Reverse Leakage @ Vr	Mounting Type	Package / Case	Voltage - DC Reverse (Vr) (Max) [Max]	Speed	Voltage - Forward (Vf) (Max) @ If	Operating Temperature - Junction	Supplier Device Package	Current - Average Rectified (Io)
Rohm Semiconductor YQ30NL10SDTL	Schottky	95 µA	Surface Mount	D2PAK (2 Leads + Tab), TO-263-3, TO-263AB	100 V	200 mA, 500 ns	990 mV	150 ¯C	TO-263L	30 A

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Cut Tape (CT)	1	$ 2.29
		10	$ 1.52
		100	$ 1.10
		500	$ 0.88
	Digi-Reel®	1	$ 2.29
		10	$ 1.52
		100	$ 1.10
		500	$ 0.88
	Tape & Reel (TR)	1000	$ 0.80
		2000	$ 0.71
		3000	$ 0.71
Newark	Each (Supplied on Cut Tape)	1	$ 2.70
		10	$ 1.45
		25	$ 1.30
		50	$ 1.15
		100	$ 1.00
		250	$ 0.96
		500	$ 0.91
		1000	$ 0.84

Description

General part information

YQ30NL10SD Series

The YQ30NL10SD is a highly efficient Schottky Barrier Diode that is designed improving the tradeoff between low VFand low IR. While its low VFit achieves stable operation at high temperatures. Ideal for switching power supplies, freewheel diodes, and reverse polarity protection applications.

Documents

Technical documentation and resources

Method for Calculating Junction Temperature from Transient Thermal Resistance Data

Thermal Design

Two-Resistor Model for Thermal Simulation

Thermal Design

Judgment Criteria of Thermal Evaluation

Thermal Design

Method for Monitoring Switching Waveform

Schematic Design & Verification

Diode Types and Applications

Technical Article

What is a Thermal Model? (Diode)

Thermal Design
