QM42VP6AF150

Obsolete

BANNER ENGINEERING

QM42 SERIES:ADJUSTABLE FIELD

Search across all available documentation for this part.

Obsolete

BANNER ENGINEERING

QM42 SERIES:ADJUSTABLE FIELD

Technical Specifications

Parameters and characteristics for this part

Specification	QM42VP6AF150

Cable Length	78.74 in
Cable Length	2 m
Connection Method	Cable
Ingress Protection	IP67
Light Source	Infrared
Operating Temperature [Max]	55 °C
Operating Temperature [Min]	-20 C
Output Configuration	PNP - Dark-ON/Light-ON - Selectable
Response Time	1 ms
Sensing Distance	5.906 in
Sensing Distance	15 cm
Sensing Method	Background Suppression
Voltage - Supply [Max]	30 VDC
Voltage - Supply [Min]	10 VDC

Part	Voltage - Supply [Max]	Voltage - Supply [Min]	Sensing Distance	Sensing Distance	Response Time	Light Source	Sensing Method	Output Configuration	Cable Length	Cable Length	Operating Temperature [Max]	Operating Temperature [Min]	Connection Method	Ingress Protection
BANNER ENGINEERING QM42VP6AF150	30 VDC	10 VDC	5.906 in	15 cm	1 ms	Infrared	Background Suppression	PNP - Dark-ON/Light-ON - Selectable	78.74 in	2 m	55 °C	-20 C	Cable	IP67

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Newark	Each	1	$ 316.00

General part information

Background Suppression Optical Sensor 5.906" (150mm) PNP - Dark-ON/Light-ON - Selectable
