AQCD3-IM100/240VAC
ObsoletePanasonic Electric Works
SSR RELAY SPST-NO 25MA 4-32V
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsHow to Read Date Codes
AQCD3-IM100/240VAC
ObsoletePanasonic Electric Works
SSR RELAY SPST-NO 25MA 4-32V
Deep-Dive with AI
DocumentsHow to Read Date Codes
Technical Specifications
Parameters and characteristics for this part
| Specification | AQCD3-IM100/240VAC |
|---|---|
| Approval Agency | UR, CSA, TUV |
| Load Current | 25 mA |
| Mounting Type | Through Hole |
| Operating Temperature [Max] | 80 C |
| Operating Temperature [Min] | -30 ░C |
| Output Type | DC |
| Package / Case | Module |
| Termination Style | PC Pin |
| Voltage - Input [Max] | 250 VAC |
| Voltage - Input [Min] | 80 VAC |
| Voltage - Load [Max] | 32 V |
| Voltage - Load [Min] | 4 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
Description
General part information
AQCD3 Series
Solid State SPST-NO (1 Form A) Module
Documents
Technical documentation and resources
