7614-6002PL
Active3M (TC)
HDR SOCKET 14 POS BTB VERT TH
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
7614-6002PL
Active3M (TC)
HDR SOCKET 14 POS BTB VERT TH
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | 7614-6002PL |
|---|---|
| Connector Type | Header |
| Contact Finish - Mating | Gold |
| Contact Finish - Post | Gold |
| Contact Finish Thickness - Mating | 0.203 Ám |
| Contact Finish Thickness - Mating | 8 Áin |
| Contact Finish Thickness - Post | Flash |
| Contact Length - Post [x] | 0.11 in |
| Contact Length - Post [x] | 2.8 mm |
| Contact Type | Male Pin |
| Insulation Color | Gray |
| Number of Positions | 14 |
| Number of Positions Loaded | All |
| Number of Rows | 2 |
| Pitch - Mating | 0.1 in |
| Pitch - Mating | 2.54 mm |
| Row Spacing - Mating [x] | 2.54 mm |
| Row Spacing - Mating [x] | 0.1 in |
| Termination | Solder |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 3.39 | |
| 10 | $ 2.59 | |||
| 100 | $ 2.00 | |||
| 500 | $ 1.68 | |||
| 1000 | $ 1.57 | |||
| 5000 | $ 1.34 | |||
Description
General part information
7614 Series
Connector Header 14 position 0.100" (2.54mm)
