EVAL BOARD FOR MAX11261
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
MAX11261SYS1#
ActiveAnalog Devices Inc./Maxim Integrated
EVAL BOARD FOR MAX11261
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics commom to parts in this series
| Specification | MAX11261SYS1# | MAX11261 Series |
|---|---|---|
| Architecture | - | Sigma-Delta |
| Configuration | - | MUX-PGA-ADC |
| Data Interface | I2C | I2C |
| Features | - | PGA |
| Input Range | ±VREF | ±VREF |
| Input Type | - | Differential |
| Mounting Type | - | Surface Mount |
| Number of A/D Converters | 1 | 1 |
| Number of Bits | 24 | 24 |
| Number of Inputs | - | 6 |
| Operating Temperature | - | 85 °C |
| Operating Temperature | - | -40 °C |
| Package / Case | - | 36-XFBGA, WLBGA |
| Ratio - S/H:ADC | - | 0:1 |
| Reference Type | - | External |
| Sampling Rate (Per Second) | 16k | 16k |
| Supplied Contents | Board(s) | Board(s) |
| Supplier Device Package | - | 2.84 |
| Supplier Device Package | - | 36-WLP |
| Supplier Device Package | - | 2.84 |
| Utilized IC / Part | MAX11261 | MAX11261 |
| Voltage - Supply, Analog | - | 2.7 V |
| Voltage - Supply, Analog | - | 3.6 V |
| Voltage - Supply, Digital | - | 3.6 V |
| Voltage - Supply, Digital | - | 1.7 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Box | 1 | $ 170.12 | |
MAX11261 Series
IC ADC 24BIT SIGMA-DELTA 36WLP
| Part | Voltage - Supply, Analog [Min] | Voltage - Supply, Analog [Max] | Number of Inputs | Number of A/D Converters | Operating Temperature [Max] | Operating Temperature [Min] | Architecture | Input Type | Ratio - S/H:ADC | Configuration | Reference Type | Data Interface | Package / Case | Features | Voltage - Supply, Digital [Max] | Voltage - Supply, Digital [Min] | Sampling Rate (Per Second) | Supplier Device Package [x] | Supplier Device Package | Supplier Device Package [y] | Number of Bits | Mounting Type | Input Range | Utilized IC / Part | Supplied Contents |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Analog Devices Inc./Maxim Integrated MAX11261ENX+T | 2.7 V | 3.6 V | 6 | 1 | 85 °C | -40 °C | Sigma-Delta | Differential | 0:1 | MUX-PGA-ADC | External | I2C | 36-XFBGA, WLBGA | PGA | 3.6 V | 1.7 V | 16k | 2.84 | 36-WLP | 2.84 | 24 | Surface Mount | |||
Analog Devices Inc./Maxim Integrated MAX11261SYS1# | 1 | I2C | 16k | 24 | ±VREF | MAX11261 | Board(s) | ||||||||||||||||||
Analog Devices Inc./Maxim Integrated MAX11261ENX+ | 2.7 V | 3.6 V | 6 | 1 | 85 °C | -40 °C | Sigma-Delta | Differential | 0:1 | MUX-PGA-ADC | External | I2C | 36-XFBGA, WLBGA | PGA | 3.6 V | 1.7 V | 16k | 2.84 | 36-WLP | 2.84 | 24 | Surface Mount |
Description
General part information
MAX11261 Series
MAX11261 - 24 Bit 16k Samples per Second Analog to Digital Converter (ADC) Evaluation Board
