BU-10PMMS-SC7001

Active

Amphenol LTW

CERES, STANDARD SIZE, PLASTIC, 2A, 10 PINS, MALE CONNECTOR, MALE CONTACT, CIRCULAR, SCREW THREAD, SOLDER, RECEPTACLE, IP67 ROHS

Search across all available documentation for this part.

Active

Amphenol LTW

CERES, STANDARD SIZE, PLASTIC, 2A, 10 PINS, MALE CONNECTOR, MALE CONTACT, CIRCULAR, SCREW THREAD, SOLDER, RECEPTACLE, IP67 ROHS

Technical Specifications

Parameters and characteristics for this part

Specification	BU-10PMMS-SC7001

Color	Black
Connector Type	Receptacle, Male Pins
Contact Finish - Mating	Gold
Contact Material	Copper Alloy
Current Rating (Amps)	2 A
Ingress Protection	IP67 - Dust Tight, Waterproof
Insert Material	Polyamide (PA), Nylon, Glass Filled
Mounting Feature	Bulkhead - Front Side Nut
Mounting Type	Through Hole, Panel Mount
Number of Positions	10
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Orientation	Keyed
Primary Material	Plastic
Shell Material	Nylon, Glass Filled, Polyamide (PA)
Shell Size - Insert	B
Shielding	Unshielded
Termination	Solder
Voltage Rating	250 VDC

Part	Ingress Protection	Primary Material	Number of Positions	Voltage Rating	Color	Mounting Feature	Insert Material	Shell Size - Insert	Current Rating (Amps)	Mounting Type	Contact Finish - Mating	Connector Type	Operating Temperature [Min]	Operating Temperature [Max]	Contact Material	Orientation	Termination	Shielding	Shell Material
Amphenol LTW BU-10PMMS-SC7001	IP67 - Dust Tight Waterproof	Plastic	10	250 VDC	Black	Bulkhead - Front Side Nut	Polyamide (PA) Nylon Glass Filled	B	2 A	Panel Mount Through Hole	Gold	Male Pins Receptacle	-40 °C	105 ░C	Copper Alloy	Keyed	Solder	Unshielded	Glass Filled Nylon Polyamide (PA)

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

10 Position Circular Connector Receptacle, Male Pins Solder
