NMB10-18GM65-E2-C-V1
ActivePEPPERL+FUCHS
INDUCTIVE PROXIMITY SENSOR, M12, 10 MM, PNP, 10 VDC TO 30 VDC
Deep-Dive with AI
Search across all available documentation for this part.
NMB10-18GM65-E2-C-V1
ActivePEPPERL+FUCHS
INDUCTIVE PROXIMITY SENSOR, M12, 10 MM, PNP, 10 VDC TO 30 VDC
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | NMB10-18GM65-E2-C-V1 |
|---|---|
| Indicator [custom] | LED |
| Ingress Protection | IP67 |
| Material - Body | Stainless Steel |
| Operating Temperature [Max] | 70 °C |
| Operating Temperature [Min] | -25 °C |
| Output Type | PNP-NO, 3-Wire |
| Package / Case | Cylinder, Threaded - M18 |
| Sensing Distance | 0.394 in |
| Sensing Distance | 10 mm |
| Sensor Type | Inductive |
| Shielding | Unshielded |
| Termination Style | Connector |
| Voltage - Supply [Max] | 30 VDC |
| Voltage - Supply [Min] | 10 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
NMB10 Series
INDUCTIVE PROXIMITY SENSOR, M12, 10 MM, PNP, 10 VDC TO 30 VDC
