74HC273FPDV-E

Active

Renesas Electronics Corporation

IC FF D-TYPE SNGL 8BIT

Search across all available documentation for this part.

Active

Renesas Electronics Corporation

IC FF D-TYPE SNGL 8BIT

Technical Specifications

Parameters and characteristics for this part

Specification	74HC273FPDV-E

Clock Frequency	122 MHz
Current - Output High, Low [custom]	5.2 mA
Current - Output High, Low [custom]	5.2 mA
Current - Quiescent (Iq)	8 ÁA
Input Capacitance	3.5 pF
Max Propagation Delay @ V, Max CL	26 ns
Number of Bits per Element	8
Number of Elements	1
Operating Temperature [Max]	125 °C
Operating Temperature [Min]	-40 °C
Output Type	Non-Inverted
Trigger Type	Positive Edge
Type	D-Type
Voltage - Supply [Max]	6 V
Voltage - Supply [Min]	2 V

IC FF D-TYPE SNGL 8BIT

Part	Input Capacitance	Operating Temperature [Min]	Operating Temperature [Max]	Clock Frequency	Current - Quiescent (Iq)	Type	Voltage - Supply [Min]	Voltage - Supply [Max]	Max Propagation Delay @ V, Max CL	Number of Elements	Output Type	Trigger Type	Number of Bits per Element	Current - Output High, Low [custom]	Current - Output High, Low [custom]
Renesas Electronics Corporation 74HC273FPDV-E	3.5 pF	-40 °C	125 °C	122 MHz	8 ÁA	D-Type	2 V	6 V	26 ns	1	Non-Inverted	Positive Edge	8	5.2 mA	5.2 mA

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	325	$ 0.92

General part information

Flip Flop 1 Element D-Type 8 Bit Positive Edge

Technical documentation and resources

No documents available
