AM30CW-4815SNZ

Active

aimtec

DC DC CONVERTER 15V 30W

Search across all available documentation for this part.

Active

aimtec

DC DC CONVERTER 15V 30W

Technical Specifications

Parameters and characteristics for this part

Specification	AM30CW-4815SNZ

Applications	ITE (Commercial)
Approval Agency	CE
Current - Output (Max) [Max]	2 A
Efficiency	88 %
Features	Remote On/Off, Adjustable Output
Mounting Type	Through Hole
Number of Outputs	1
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	6-DIP Module
Power (Watts)	30 W
Size / Dimension [x]	25.4 mm
Size / Dimension [x]	25.4 mm
Size / Dimension [y]	25.4 mm
Size / Dimension [y]	25.4 mm
Size / Dimension [z]	0.46 in
Size / Dimension [z]	11.7 mm
Standard Number	62368-1
Type	Isolated Module
Voltage - Input (Max) [Max]	75 V
Voltage - Input (Min) [Min]	18 V
Voltage - Isolation	1.5 kV
Voltage - Output 1	15 V

Part	Standard Number	Mounting Type	Type	Package / Case	Voltage - Input (Max) [Max]	Current - Output (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [z]	Size / Dimension [y]	Size / Dimension [x]	Voltage - Isolation	Approval Agency	Efficiency	Voltage - Output 1	Features	Applications	Power (Watts)	Voltage - Input (Min) [Min]	Number of Outputs
aimtec AM30CW-4815SNZ	62368-1	Through Hole	Isolated Module	6-DIP Module	75 V	2 A	85 °C	-40 °C	25.4 mm	0.46 in	25.4 mm	11.7 mm	25.4 mm	25.4 mm	1.5 kV	CE	88 %	15 V	Adjustable Output Remote On/Off	ITE (Commercial)	30 W	18 V	1

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Isolated Module DC DC Converter 1 Output 15V 2A 18V - 75V Input
