PWH-05PMMC-LC8001

Active

Amphenol LTW

POWER, PWH, 25A, 05 PINS, RECEPT

Search across all available documentation for this part.

Active

Amphenol LTW

POWER, PWH, 25A, 05 PINS, RECEPT

Technical Specifications

Parameters and characteristics for this part

Specification	PWH-05PMMC-LC8001

Color	Black
Connector Type	Receptacle, Male Pins
Contact Material	Copper
Current Rating (Amps)	25 A
Fastening Type	Bayonet Lock
Ingress Protection	IP68 - Dust Tight, Waterproof
Insert Material	Polyphenylene Ether (PPE)
Material Flammability Rating	UL94 V-0
Mounting Feature	Bulkhead - Front Side Nut
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Orientation	Keyed
Primary Material	Plastic
Shell Material	Polyphenylene Ether (PPE)
Shielding	Unshielded
Termination	Crimp
Voltage Rating	1000 VDC, 660 VAC

Part	Connector Type	Current Rating (Amps)	Shielding	Material Flammability Rating	Termination	Ingress Protection	Voltage Rating	Color	Contact Material	Insert Material	Operating Temperature [Min]	Operating Temperature [Max]	Shell Material	Mounting Feature	Primary Material	Orientation	Fastening Type
Amphenol LTW PWH-05PMMC-LC8001	Male Pins Receptacle	25 A	Unshielded	UL94 V-0	Crimp	IP68 - Dust Tight Waterproof	660 VAC 1000 VDC	Black	Copper	Polyphenylene Ether (PPE)	-40 °C	105 ░C	Polyphenylene Ether (PPE)	Bulkhead - Front Side Nut	Plastic	Keyed	Bayonet Lock

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

5 Position Circular Connector Receptacle, Male Pins Crimp
