P25P42D22P1-12

Obsolete

TE Connectivity Potter & Brumfield Relays

RELAY CONTACTOR 3PST 25A 12V

Search across all available documentation for this part.

Obsolete

TE Connectivity Potter & Brumfield Relays

RELAY CONTACTOR 3PST 25A 12V

Technical Specifications

Parameters and characteristics for this part

Specification	P25P42D22P1-12

Coil Current	353 mA
Coil Power	8 W
Coil Resistance	34 Ohms
Coil Voltage	12 VDC
Contact Form	DM
Contact Form	3PST-NO
Contact Form	3 Form X
Contact Material	Silver Cadmium Oxide (AgCdO)
Contact Rating (Current)	25 A
Mounting Type	Chassis Mount
Must Operate Voltage	9 VDC
Operating Temperature [Max]	55 °C
Operating Temperature [Min]	-55 °C
Switching Voltage	600 VAC
Termination Style	Screw Terminal, Quick Connect
Termination Style	0.25 in

Part	Coil Resistance	Switching Voltage	Coil Voltage	Operating Temperature [Min]	Operating Temperature [Max]	Termination Style	Termination Style	Contact Material	Contact Rating (Current)	Mounting Type	Coil Power	Contact Form	Contact Form	Contact Form	Must Operate Voltage	Coil Current
TE Connectivity Potter & Brumfield Relays P25P42D22P1-24	133 Ohms	600 VAC	24 VDC	-55 °C	55 °C	Quick Connect Screw Terminal	0.25 in	Silver Cadmium Oxide (AgCdO)	25 A	Chassis Mount	8 W	DM	3PST-NO	3 Form X	18 VDC	180 mA
TE Connectivity Potter & Brumfield Relays P25P42A12P1-240		600 VAC	240 VAC	-55 °C	65 °C	Quick Connect Screw Terminal	0.25 in	Silver Cadmium Oxide (AgCdO)	25 A	Chassis Mount	10 VA	DM	3PST-NO	3 Form X	177 VAC
TE Connectivity Potter & Brumfield Relays P25P42D22P1-12	34 Ohms	600 VAC	12 VDC	-55 °C	55 °C	Quick Connect Screw Terminal	0.25 in	Silver Cadmium Oxide (AgCdO)	25 A	Chassis Mount	8 W	DM	3PST-NO	3 Form X	9 VDC	353 mA
TE Connectivity Potter & Brumfield Relays P25P42A22P1-240		600 VAC	240 VAC	-55 °C	65 °C	Quick Connect Screw Terminal	0.25 in	Silver Cadmium Oxide (AgCdO)	25 A	Chassis Mount	10 VA	DM	3PST-NO	3 Form X	177 VAC

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

RELAY CONTACTOR 3PST 25A 12V
