Technical Specifications
Parameters and characteristics for this part
| Specification | CSU1300AP-3-600 |
|---|---|
| Applications | ITE (Commercial) |
| Approval Agency | cUL, CCC, TUV, KC, UL, CE, CB |
| Current - Output 1 | 108.3 A |
| Minimum Load Required | True |
| Mounting Type | Rack Mount |
| Number of Outputs | 1 |
| Power (Watts) | 1321 W |
| Size / Dimension [x] | 7.28 in |
| Size / Dimension [x] | 185 mm |
| Size / Dimension [y] | 2.89 in |
| Size / Dimension [y] | 73.5 mm |
| Size / Dimension [z] | 39 mm |
| Size / Dimension [z] | 1.54 " |
| Type | Front End |
| Voltage - Input [Max] | 264 VAC, 300 VDC |
| Voltage - Input [Min] | 90 VAC, 180 V |
| Voltage - Output 1 | 12.2 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
CSU1300 Series
Front End AC DC Converters 1 Output 12.2V 90 ~ 264 VAC, 180 ~ 300 VDC Input
