SRN5040TA-680K

Active

Bourns Inc.

INDUCTOR, AEC-Q200, SEMI-SHLD, 68UH/0.8A

Search across all available documentation for this part.

Active

Bourns Inc.

INDUCTOR, AEC-Q200, SEMI-SHLD, 68UH/0.8A

Technical Specifications

Parameters and characteristics for this part

Part	Frequency - Self Resonant	Mounting Type	Current - Saturation (Isat)	Material - Core	Tolerance	DC Resistance (DCR)	Type	Inductance Frequency - Test	Inductance	Package / Case	Q @ Freq	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Current Rating (Amps)	Shielding	Operating Temperature [Min]	Operating Temperature [Max]	Ratings	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [x]
Bourns Inc. SRN5040TA-680K	10 MHz	Surface Mount	900 mA	Ferrite	10 %	400 mOhm	Drum Core Wirewound	100 kHz	68 µH	Nonstandard	15 100 kHz	4.1 mm	0.161 "	800 mA	Shielded	-55 °C	125 °C	AEC-Q200	0.195 in	4.95 mm	4.95 mm	0.195 "
Bourns Inc. SRN5040TA-R60M	250 MHz	Surface Mount	11 A	Ferrite	20 %	8 mOhm	Drum Core Wirewound	100 kHz	600 nH	Nonstandard	15 100 kHz	4.1 mm	0.161 "	8 A	Shielded	-55 °C	125 °C	AEC-Q200	0.195 in	4.95 mm	4.95 mm	0.195 "
Bourns Inc. SRN5040TA-101K	7 MHz	Surface Mount	750 mA	Ferrite	10 %	560 mOhm	Drum Core Wirewound	100 kHz	100 µH	Nonstandard	15 100 kHz	4.1 mm	0.161 "	0.72 A	Shielded	-55 °C	125 °C	AEC-Q200	0.195 in	4.95 mm	4.95 mm	0.195 "
Bourns Inc. SRN5040TA-150M	22 MHz	Surface Mount	2 A	Ferrite	20 %	80 mOhm	Drum Core Wirewound	100 kHz	15 µH	Nonstandard	15 100 kHz	4.1 mm	0.161 "	1.8 A	Shielded	-55 °C	125 °C	AEC-Q200	0.195 in	4.95 mm	4.95 mm	0.195 "

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

68 µH Shielded Drum Core, Wirewound Inductor 800 mA 400mOhm Nonstandard
