FN2500-25-08-C13
ActiveTE Connectivity Raychem Cable Protection
FN2500-25-08-C13
Deep-Dive with AI
Search across all available documentation for this part.
FN2500-25-08-C13
ActiveTE Connectivity Raychem Cable Protection
FN2500-25-08-C13
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | FN2500-25-08-C13 |
|---|---|
| Applications | General Purpose |
| Approval Agency | CSA, CE, CQC, UKCA, ENEC, UR |
| Configuration | Single Stage |
| Current | 25 A |
| Filter Type | Single Phase |
| Frequency - Operating [Max] | 60 Hz |
| Frequency - Operating [Min] | DC |
| Inductance | 1.5 mH |
| Mounting Type | Chassis Mount |
| Operating Temperature [Max] | 100 °C |
| Operating Temperature [Min] | -40 °C |
| Termination Style | Threaded Post (M4) |
| Voltage - Rated AC | 277 V |
| Voltage - Rated DC | 400 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Bulk | 1 | $ 48.11 | |
Description
General part information
Schaffner FN2500 Series
25 A Single Phase Filter, Threaded Stud Input, Threaded Stud Output, 277 VAC, Schaffner FN2500, Single Phase Filters
Documents
Technical documentation and resources
