TB6568KQ,8
ActiveToshiba Semiconductor and Storage
IC MOTOR DRIVER 10V-45V 7HSIP
Deep-Dive with AI
Search across all available documentation for this part.
DocumentsDatasheet
TB6568KQ,8
ActiveToshiba Semiconductor and Storage
IC MOTOR DRIVER 10V-45V 7HSIP
Deep-Dive with AI
DocumentsDatasheet
Technical Specifications
Parameters and characteristics for this part
| Specification | TB6568KQ,8 |
|---|---|
| Applications | General Purpose |
| Current - Output | 1.5 A |
| Function | Driver - Fully Integrated, Control and Power Stage |
| Interface | Parallel |
| Motor Type - AC, DC | Brushed DC |
| Mounting Type | Through Hole |
| Operating Temperature [Max] | 85 °C |
| Operating Temperature [Min] | -40 °C |
| Output Configuration | Half Bridge (2) |
| Package / Case | 7-SIP Exposed Tab |
| Supplier Device Package | 7-HSIP |
| Technology | Bi-CMOS |
| Voltage - Load [Max] | 45 V |
| Voltage - Load [Min] | 10 V |
| Voltage - Supply [Max] | 45 V |
| Voltage - Supply [Min] | 10 VDC |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tray | 1 | $ 4.44 | |
| 10 | $ 2.87 | |||
| 25 | $ 2.46 | |||
| 80 | $ 2.06 | |||
| 230 | $ 1.79 | |||
| 440 | $ 1.65 | |||
| 945 | $ 1.52 | |||
| 2400 | $ 1.48 | |||
Description
General part information
TB6568 Series
Motor Driver Bi-CMOS Parallel 7-HSIP
