DPS1113FIA-13
ActiveUSB POWER SW POWER DELIVERY SINGLE 4.5V TO 24V 3A 17-PIN VQFN T/R
Deep-Dive with AI
Search across all available documentation for this part.
DPS1113FIA-13
ActiveUSB POWER SW POWER DELIVERY SINGLE 4.5V TO 24V 3A 17-PIN VQFN T/R
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | DPS1113FIA-13 |
|---|---|
| Current - Output (Max) [Max] | 3.5 A |
| Fault Protection | Current Limiting (Adjustable), Reverse Current, UVLO, Over Voltage, Over Temperature |
| Features | Load Discharge |
| Interface | On/Off |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Operating Temperature [Max] | 125 ¯C |
| Operating Temperature [Min] | -40 °C |
| Output Configuration | High Side |
| Package / Case | 17-VFQFN Exposed Pad |
| Ratio - Input:Output [custom] | 1:1 |
| Rds On (Typ) | 29 mOhm |
| Supplier Device Package | V-QFN4040-17 |
| Switch Type | USB Switch |
| Voltage - Load [Max] | 5.5 V |
| Voltage - Load [Min] | 4.5 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 1.29 | |
| 10 | $ 0.82 | |||
| 25 | $ 0.70 | |||
| 100 | $ 0.56 | |||
| 250 | $ 0.49 | |||
| 500 | $ 0.45 | |||
| 1000 | $ 0.44 | |||
| Digi-Reel® | 1 | $ 1.29 | ||
| 10 | $ 0.82 | |||
| 25 | $ 0.70 | |||
| 100 | $ 0.56 | |||
| 250 | $ 0.49 | |||
| 500 | $ 0.45 | |||
| 1000 | $ 0.44 | |||
| Tape & Reel (TR) | 4000 | $ 0.44 | ||
Description
General part information
DPS1113 Series
The DPS1113 is part of a family of power switches optimized for USBPower Delivery and other hot-swap applications. Through the analoginterface, exception status is reported and several functions can beprogrammed: current limit, overvoltage protection, and output voltageramping up. The fast role swap function which complies to therequirement defined in the USB Power Delivery Specification Release3.0, V1.0a is implemented.
