ISV0212D15
ActiveISOLATED SURFACE MOUNT DC/DC CONVERTER, ITE, 4:1, 2 W, 2 OUTPUT, 15 V, 67 MA
Deep-Dive with AI
Search across all available documentation for this part.
ISV0212D15
ActiveISOLATED SURFACE MOUNT DC/DC CONVERTER, ITE, 4:1, 2 W, 2 OUTPUT, 15 V, 67 MA
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | ISV0212D15 |
|---|---|
| Applications | ITE (Commercial) |
| Current - Output (Max) | 67 mA |
| Current - Output (Max) | 67 mA |
| Efficiency | 81 % |
| Features | Remote On/Off |
| Mounting Type | Surface Mount |
| Number of Outputs | 2 |
| Operating Temperature [Max] | 75 ░C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 6-SMD Module |
| Power (Watts) | 2 W |
| Size / Dimension [x] | 14.7 mm |
| Size / Dimension [x] | 0.58 in |
| Size / Dimension [y] | 0.57 in |
| Size / Dimension [y] | 14.4 mm |
| Size / Dimension [z] | 0.35 " |
| Size / Dimension [z] | 9 mm |
| Type | Isolated Module |
| Voltage - Input (Max) [Max] | 18 V |
| Voltage - Input (Min) [Min] | 4.5 V |
| Voltage - Isolation | 3000 V |
| Voltage - Output 1 | 15 V |
| Voltage - Output 2 | -15 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
ISV0212 Series
The ISV02 series is a compact SMD, open frame construction providing a cost effective DC-DC converter with high performance features such as 3.0kV isolation, 4:1 input range, full load operating temperature to 75°C, remote on/off, high reliabity and short circuit protection. Available in single or dual output versions this product family is ideal for signal conditioning and voltage matching.
