SRF0905A-471Y
ActiveBourns Inc.
COMMON MODE CHOKES DUAL 470UH 1KOHM 100KHZ 1.1A 0.14OHM DCR SMD AUTOMOTIVE AEC-Q200 T/R
Deep-Dive with AI
Search across all available documentation for this part.
SRF0905A-471Y
ActiveBourns Inc.
COMMON MODE CHOKES DUAL 470UH 1KOHM 100KHZ 1.1A 0.14OHM DCR SMD AUTOMOTIVE AEC-Q200 T/R
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | SRF0905A-471Y |
|---|---|
| Current Rating (Max) [Max] | 1.1 A |
| DC Resistance (DCR) (Max) [Max] | 140 mOhm |
| Height (Max) [Max] | 6.3 mm |
| Height (Max) [Max] | 0.248 in |
| Impedance @ Frequency | 1 kOhms |
| Inductance @ Frequency | 470 µH |
| Mounting Type | Surface Mount |
| Number of Lines | 2 |
| Operating Temperature [Max] | 105 ░C |
| Operating Temperature [Min] | -40 °C |
| Package / Case | 4 Lead |
| Package / Case | Horizontal |
| Size / Dimension [x] | 9.2 mm |
| Size / Dimension [x] | 0.362 in |
| Size / Dimension [y] | 6 mm |
| Size / Dimension [y] | 0.236 in |
| Voltage Rating - DC | 80 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Cut Tape (CT) | 1 | $ 1.43 | |
| 10 | $ 1.21 | |||
| 25 | $ 1.10 | |||
| 50 | $ 1.04 | |||
| 100 | $ 0.86 | |||
| 250 | $ 0.79 | |||
| 500 | $ 0.75 | |||
| Digi-Reel® | 1 | $ 1.43 | ||
| 10 | $ 1.21 | |||
| 25 | $ 1.10 | |||
| 50 | $ 1.04 | |||
| 100 | $ 0.86 | |||
| 250 | $ 0.79 | |||
| 500 | $ 0.75 | |||
| Tape & Reel (TR) | 1000 | $ 0.68 | ||
| 3000 | $ 0.66 | |||
| 5000 | $ 0.64 | |||
| 10000 | $ 0.62 | |||
| Newark | Each (Supplied on Full Reel) | 2000 | $ 0.69 | |
| 4000 | $ 0.62 | |||
| 6000 | $ 0.59 | |||
| 10000 | $ 0.58 | |||
Description
General part information
SRF0905A Series
470 µH @ 100 kHz 2 Line Common Mode Choke Surface Mount 1 kOhms @ 2 MHz 1.1A DCR 140mOhm
