FNR-1-Y-P-1-BK

Active

Ruffy Controls Inc.

SWITCH ROCKER THUMBWHEEL HALL 5V

Search across all available documentation for this part.

Active

Ruffy Controls Inc.

SWITCH ROCKER THUMBWHEEL HALL 5V

Technical Specifications

Parameters and characteristics for this part

Specification	FNR-1-Y-P-1-BK

Actuator Type	Thumbwheel
Ingress Protection	IP67 - Dust Tight, Waterproof
Mechanical Life	3000000 Cycles
Operating Temperature [Max]	60 °C
Operating Temperature [Min]	-20 C
Output	Analog (Hall Effect)
Panel Cutout Dimensions [diameter]	25 mm
Switch Function	2-Way Directional
Type	Rockerswitch, 1 - Axis
Voltage - Supply	5 V
Voltage Rating - DC	5 V

SWITCH ROCKER THUMBWHEEL HALL 5V

Part	Switch Function	Operating Temperature [Min]	Operating Temperature [Max]	Actuator Type	Ingress Protection	Mechanical Life	Voltage - Supply	Output	Type	Voltage Rating - DC	Panel Cutout Dimensions [diameter]
Ruffy Controls Inc. FNR-1-Y-P-1-BK	2-Way Directional	-20 C	60 °C	Thumbwheel	IP67 - Dust Tight, Waterproof	3000000 Cycles	5 V	Analog (Hall Effect)	Rockerswitch, 1 - Axis	5 V	25 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Rockerswitch, 1 - Axis Analog (Hall Effect) Output

Technical documentation and resources
