AZSR143-1AE-24D

Active

American Zettler

RELAY EV CHG SOLAR SPST 50A 24V

Search across all available documentation for this part.

Active

American Zettler

RELAY EV CHG SOLAR SPST 50A 24V

Technical Specifications

Parameters and characteristics commom to parts in this series

RELAY EV CHG SOLAR SPST 50A 12V

Part	Load - Max Switching [Max]	Contact Form	Coil Resistance	Must Release Voltage	Mounting Type	Termination Style	Operate Time	Must Operate Voltage	Coil Type	Operating Temperature [Max]	Operating Temperature [Min]	Switching Voltage [Max]	Relay Type	Contact Rating (Current)	Release Time	Contact Material	Approval Agency	Coil Current	Coil Voltage	Coil Insulation
American Zettler AZSR143-1AE-12D	19200 VA	SPST-NO (1 Form A)	90 Ohms	0.6 VDC	Through Hole	PC Pin	20 ms	9 VDC	Non Latching	85 °C	-40 °C	277 VAC	EV Charging, Solar	50 A	10 ms	Silver Tin Oxide (AgSnO)	CQC, cURus, TUV	133.3 mA	12 VDC	Class F
American Zettler AZSR143-1AE-24D	19200 VA	SPST-NO (1 Form A)	360 Ohms	1.2 VDC	Through Hole	PC Pin	20 ms	18 VDC	Non Latching	85 °C	-40 °C	277 VAC	EV Charging, Solar	50 A	10 ms	Silver Tin Oxide (AgSnO)	CQC, cURus, TUV	66.7 mA	24 VDC	Class F

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

EV Charging, Solar Relay SPST-NO (1 Form A) 24VDC Coil Through Hole
