KX15-100K4DE

Obsolete

JAE Electronics

CONN PLUG 100POS SMD GOLD

Search across all available documentation for this part.

Obsolete

JAE Electronics

CONN PLUG 100POS SMD GOLD

Technical Specifications

Parameters and characteristics for this part

Specification	KX15-100K4DE

Contact Finish	Gold
Contact Finish Thickness	4 Áin
Contact Finish Thickness	0.1 Ám
Features	Solder Retention, Board Guide
Height Above Board	0.226 in
Height Above Board	5.74 mm
Mated Stacking Heights	6 mm, 12 mm, 15 mm, 18 mm, 9 mm
Mounting Type	Surface Mount
Number of Positions	100
Number of Rows	2
Pitch [x]	0.8 mm
Pitch [x]	0.031 in

Part	Mated Stacking Heights	Pitch [x]	Pitch [x]	Mounting Type	Contact Finish	Number of Positions	Number of Rows	Features	Height Above Board	Height Above Board	Contact Finish Thickness	Contact Finish Thickness
JAE Electronics KX15-100K3D-E300E
JAE Electronics KX15-100K4DE	6 mm 9 mm 12 mm 15 mm 18 mm	0.8 mm	0.031 in	Surface Mount	Gold	100	2	Board Guide Solder Retention	0.226 in	5.74 mm	4 Áin	0.1 Ám

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

100 Position Connector Plug, Center Strip Contacts Surface Mount Gold
