ECMF02-4CMX8 - ECMF Series 8-UQFN

ECMF02-4CMX8

Active
STMicroelectronics

COMMON MODE FILTER WITH ESD PROTECTION -33DB 5.5V SOLDER SMD 8-PIN UQFN T/R

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheetDatasheet+17
ECMF02-4CMX8 - ECMF Series 8-UQFN

ECMF02-4CMX8

Active
STMicroelectronics

COMMON MODE FILTER WITH ESD PROTECTION -33DB 5.5V SOLDER SMD 8-PIN UQFN T/R

Deep-Dive with AI

DocumentsDatasheetDatasheet+17

Technical Specifications

Parameters and characteristics commom to parts in this series

SpecificationECMF02-4CMX8ECMF02 Series
--
DC Resistance (DCR) (Max) [Max]4 Ohm4 Ohm
FeaturesTVS Diode ESD ProtectionTVS Diode ESD Protection
Height (Max)0.55 mm0.55 mm
Height (Max) [Max]0.022 in0.022 in
Mounting TypeSurface MountSurface Mount
Number of Lines22
Operating Temperature [Max]125 °C85 - 125 °C
Operating Temperature [Min]-40 °C-40 - -30 °C
Package / Case8-UFDFN8-UFDFN
Size / Dimension [x]2.5 mm2.5 mm
Size / Dimension [x]0.098 "0.098 "
Size / Dimension [y]1.2 mm1.2 mm
Size / Dimension [y]0.047 in0.047 in
