M22-3070200

Active

Harwin Inc.

HEADER CONNECTOR,CABLE MOUNT,PLUG,2 CONTACTS,SKT,0.079 PITCH ROHS COMPLIANT: YES

Search across all available documentation for this part.

Active

Harwin Inc.

HEADER CONNECTOR,CABLE MOUNT,PLUG,2 CONTACTS,SKT,0.079 PITCH ROHS COMPLIANT: YES

Technical Specifications

Parameters and characteristics for this part

Part	Note	Color	Number of Positions	Number of Rows	Mounting Type	Contact Type	Connector Type	Contact Termination	Insulation Material	Operating Temperature [Min]	Operating Temperature [Max]	Pitch [x]	Pitch [x]
Harwin Inc. M22-3070200	Contacts Not Included	Natural	2	1	Free Hanging (In-Line)	Female Socket	Receptacle	Crimp	Thermoplastic	-25 °C	85 °C	0.079 in	2 mm
Harwin Inc. M22-3070400	Contacts Not Included	Natural	4	1	Free Hanging (In-Line)	Female Socket	Receptacle	Crimp	Thermoplastic	-25 °C	85 °C	0.079 in	2 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

2 Rectangular Connectors - Housings Receptacle Natural 0.079" (2.00mm)
