Specification	430052-501

Current - Max	6 A
Delta Tmax	65 °C
Features	Non-Sealed, Lead Wires
Height	3.63 mm
Maximum Power Dissipation (Qmax)	52.2 W
Number of Stages	1
Operating Temperature	80 °C
Resistance	2.19 Ohms
Size / Dimension Length	43.9 mm
Size / Dimension Shape	Rectangular
Size / Dimension Width	39.9 mm
Voltage - Max	14.5 V

430052 Series

Part	Current - Max	Number of Stages	Maximum Power Dissipation (Qmax)	Height	Operating Temperature	Features	Size / Dimension Shape	Size / Dimension Width	Size / Dimension Length	Voltage - Max	Resistance	Delta Tmax
Laird Thermal Systems, Inc. 430052-505	6 A	1	52.3 W	3.63 mm	80 °C	Epoxy Lead Wires Sealed	Rectangular	39.9 mm	43.9 mm	14.5 V	2.19 Ohms	65 °C
Laird Thermal Systems, Inc. 430052-501	6 A	1	52.2 W	3.63 mm	80 °C	Lead Wires Non-Sealed	Rectangular	39.9 mm	43.9 mm	14.5 V	2.19 Ohms	65 °C
