C4DCMAQ4600AA0J

Active

KEMET

CAP FILM 6UF 5% 850VDC AXIAL

Search across all available documentation for this part.

Active

KEMET

CAP FILM 6UF 5% 850VDC AXIAL

Technical Specifications

Parameters and characteristics for this part

Specification	C4DCMAQ4600AA0J

Applications	DC Filtering, High Pulse, DC Link, DV/DT
Capacitance	6 µF
Dielectric Material	Metallized, Polypropylene (PP)
ESR (Equivalent Series Resistance)	1 mOhms
Height - Seated (Max) [Max]	51 mm
Height - Seated (Max) [Max] [z]	2.008 in
Mounting Type	Chassis Mount
Operating Temperature [Max]	85 °C
Operating Temperature [Min]	-40 °C
Package / Case	Axial, Can - Screw Terminals
Size / Dimension [diameter]	3.543 in
Size / Dimension [diameter]	90 mm
Termination	Threaded, Female
Tolerance	5 %
Voltage Rating - AC	500 V
Voltage Rating - DC	850 V

Part	Size / Dimension [diameter]	Size / Dimension [diameter]	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max]	Operating Temperature [Max]	Operating Temperature [Min]	Capacitance	Package / Case	ESR (Equivalent Series Resistance)	Termination	Voltage Rating - DC	Mounting Type	Dielectric Material	Tolerance	Voltage Rating - AC	Applications
KEMET C4DCMAQ4600AA0J	3.543 in	90 mm	2.008 in	51 mm	85 °C	-40 °C	6 µF	Axial Can - Screw Terminals	1 mOhms	Threaded Female	850 V	Chassis Mount	Metallized Polypropylene (PP)	5 %	500 V	DC Filtering DC Link DV/DT High Pulse

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	72	$ 63.50
Newark	Each	50	$ 64.74
		100	$ 61.01

General part information

6 µF Film Capacitor 500V 850V Polypropylene (PP), Metallized Axial, Can - Screw Terminals
