PAM8001XHR

Obsolete

Diodes Inc

AUDIO AMP SPEAKER 2-CH STEREO 2.8W CLASS-D 20-PIN QFN EP T/R

Search across all available documentation for this part.

Obsolete

Diodes Inc

AUDIO AMP SPEAKER 2-CH STEREO 2.8W CLASS-D 20-PIN QFN EP T/R

Technical Specifications

Parameters and characteristics for this part

Specification	PAM8001XHR

Features	Short-Circuit, Thermal Protection, Depop
Max Output Power x Channels @ Load	2.8 W
Max Output Power x Channels @ Load [custom]	2
Mounting Type	Surface Mount
Operating Temperature [Max]	85 C
Operating Temperature [Min]	-20 °C
Output Type	2-Channel (Stereo)
Package / Case	20-WFQFN Exposed Pad
Supplier Device Package	20-QFN (3x3)
Type	Class D
Voltage - Supply [Max]	5.5 V
Voltage - Supply [Min]	2.5 V

NRND = Not Recommended for New Design

Part	Features	Package / Case	Max Output Power x Channels @ Load	Max Output Power x Channels @ Load [custom]	Output Type	Mounting Type	Supplier Device Package	Type	Voltage - Supply [Min]	Voltage - Supply [Max]	Operating Temperature [Min]	Operating Temperature [Max]	Package / Case [custom]
Diodes Inc PAM8001XHR	Depop Short-Circuit Thermal Protection	20-WFQFN Exposed Pad	2.8 W	2	2-Channel (Stereo)	Surface Mount	20-QFN (3x3)	Class D	2.5 V	5.5 V	-20 °C	85 C
Diodes Inc PAM8001NHR	Depop Short-Circuit Thermal Protection	24-SSOP	2.8 W	2	2-Channel (Stereo)	Surface Mount	24-SSOP	Class D	2.5 V	5.5 V	-20 °C	85 C	0.154 " 3.9 mm
