OD9232-12LB02A

Active

Orion Fans

FAN AXIAL 92X32MM 12VDC WIRE

Search across all available documentation for this part.

Active

Orion Fans

FAN AXIAL 92X32MM 12VDC WIRE

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	520	$ 11.73

General part information

Fan Tubeaxial 12VDC Square - 92mm L x 92mm H Ball 3 Wire Leads

Technical documentation and resources

No documents available

Parameters and characteristics commom to parts in this series

Specification	OD9232-12LB02A	OD9232 Series

Approval Agency	cURus, TUV	cURus, TUV
Bearing Type	Ball	Ball
Fan Type	Tubeaxial	Tubeaxial
Features	Locked Rotor Sensor	Locked Rotor Sensor, Speed Sensor (Tach)
Material - Blade	Polybutylene Terephthalate (PBT), Fiberglass Reinforced	Polybutylene Terephthalate (PBT), Fiberglass Reinforced
Material - Frame	Polybutylene Terephthalate (PBT), Fiberglass Reinforced	Polybutylene Terephthalate (PBT), Fiberglass Reinforced
Termination	3 Wire Leads	2 Wire Leads, 3 Wire Leads
Voltage - Rated	12 VDC	12 VDC
Width [y]	32 mm	32 mm

FAN AXIAL 92X32MM 12VDC WIRE

Part	Fan Type	Voltage - Rated	Width [y]	Bearing Type	Material - Frame	Approval Agency	Material - Blade	Termination	Features
Orion Fans OD9232-12LB	Tubeaxial	12 VDC	32 mm	Ball	Polybutylene Terephthalate (PBT), Fiberglass Reinforced	cURus, TUV	Polybutylene Terephthalate (PBT), Fiberglass Reinforced	2 Wire Leads
Orion Fans OD9232-12LB02A	Tubeaxial	12 VDC	32 mm	Ball	Polybutylene Terephthalate (PBT), Fiberglass Reinforced	cURus, TUV	Polybutylene Terephthalate (PBT), Fiberglass Reinforced	3 Wire Leads	Locked Rotor Sensor
Orion Fans OD9232-12MB01A	Tubeaxial	12 VDC	32 mm	Ball	Polybutylene Terephthalate (PBT), Fiberglass Reinforced	cURus, TUV	Polybutylene Terephthalate (PBT), Fiberglass Reinforced	3 Wire Leads	Speed Sensor (Tach)
Orion Fans OD9232-12MB	Tubeaxial	12 VDC	32 mm	Ball	Polybutylene Terephthalate (PBT), Fiberglass Reinforced	cURus, TUV	Polybutylene Terephthalate (PBT), Fiberglass Reinforced	2 Wire Leads
Orion Fans OD9232-12LB01A	Tubeaxial	12 VDC	32 mm	Ball	Polybutylene Terephthalate (PBT), Fiberglass Reinforced	cURus, TUV	Polybutylene Terephthalate (PBT), Fiberglass Reinforced	3 Wire Leads	Speed Sensor (Tach)
Orion Fans OD9232-12MB02A	Tubeaxial	12 VDC	32 mm	Ball	Polybutylene Terephthalate (PBT), Fiberglass Reinforced	cURus, TUV	Polybutylene Terephthalate (PBT), Fiberglass Reinforced	3 Wire Leads	Locked Rotor Sensor
