Specification	UA78LEVM-075

Board Type	Fully Populated
Channels per IC (Count)	1
Channels per IC (Single)	1
Channels per IC (Type)	Single
Contents	Board
Current - Output	100 mA
Regulator Type	Positive Fixed
Supplied Contents	Board(s)
Utilized IC / Part	UA78L05C
Voltage - Input (Maximum)	20 V
Voltage - Input (Minimum)	7 V
Voltage - Output	5 VDC

UA78L05 Series

Part	Package Length	Package Name	Package Width	Mounting Type	Operating Temperature (Max)	Operating Temperature (Min)	Voltage - Input (Max)	Output Type	Voltage - Output (Min/Fixed)	PSRR	Current - Output	Protection Features	Output Configuration	Number of Regulators	Voltage Dropout (Max)	Package / Case
Texas Instruments UA78L05ACDE4	0.154 in	8-SOIC	3.9 mm	Surface Mount	125 °C	0 °C	20 V	Fixed	5 V	49 dB	100 mA	Over Current Over Temperature Reverse Polarity Short Circuit	Positive	1	1.7 V
Texas Instruments UA78L05ACDRG4	0.154 in	8-SOIC	3.9 mm	Surface Mount	125 °C	0 °C	20 V	Fixed	5 V	49 dB	100 mA	Over Current Over Temperature Reverse Polarity Short Circuit	Positive	1	1.7 V
Texas Instruments UA78L05ACDRE4	0.154 in	8-SOIC	3.9 mm	Surface Mount	125 °C	0 °C	20 V	Fixed	5 V	49 dB	100 mA	Over Current Over Temperature Reverse Polarity Short Circuit	Positive	1	1.7 V
Texas Instruments UA78L05CLP		TO-92-3		Through Hole	125 °C	0 °C	20 V	Fixed	5 V	49 dB	100 mA	Over Current Over Temperature Reverse Polarity Short Circuit	Positive	1	1.7 V	TO-226-3 TO-92-3 (TO-226AA)
Texas Instruments UA78L05ACLPRE3		TO-92-3		Through Hole	125 °C	0 °C	20 V	Fixed	5 V	49 dB	100 mA	Over Current Over Temperature Reverse Polarity Short Circuit	Positive	1	1.7 V	TO-226-3 TO-92-3 (TO-226AA) Formed Leads
Texas Instruments UA78L05ACPK		SOT-89-3		Surface Mount	125 °C	0 °C	20 V	Fixed	5 V	49 dB	100 mA	Over Current Over Temperature Reverse Polarity Short Circuit	Positive	1	1.7 V	TO-243AA
Texas Instruments UA78L05CLPE3		TO-92-3		Through Hole	125 °C	0 °C	20 V	Fixed	5 V	49 dB	100 mA	Over Current Over Temperature Reverse Polarity Short Circuit	Positive	1	1.7 V	TO-226-3 TO-92-3 (TO-226AA)
Texas Instruments UA78L05ACLPR		TO-92-3		Through Hole	125 °C	0 °C	20 V	Fixed	5 V	49 dB	100 mA	Over Current Over Temperature Reverse Polarity Short Circuit	Positive	1	1.7 V	TO-226-3 TO-92-3 (TO-226AA) Formed Leads
Texas Instruments UA78L05AIPK		SOT-89-3		Surface Mount	125 °C	-40 °C	20 V	Fixed	5 V	49 dB	100 mA	Over Current Over Temperature Reverse Polarity Short Circuit	Positive	1	1.7 V	TO-243AA
Texas Instruments UA78L05CPK		SOT-89-3		Surface Mount	125 °C	0 °C	20 V	Fixed	5 V	49 dB	100 mA	Over Current Over Temperature Reverse Polarity Short Circuit	Positive	1	1.7 V	TO-243AA
