JCD0548S3V3

Active

XP POWER

ISOLATED THROUGH HOLE DC/DC CONVERTER, ITE, DIP, 2:1, 5 W, 1 OUTPUT, 3.3 V

Search across all available documentation for this part.

Active

XP POWER

ISOLATED THROUGH HOLE DC/DC CONVERTER, ITE, DIP, 2:1, 5 W, 1 OUTPUT, 3.3 V

Technical Specifications

Parameters and characteristics for this part

Part	Type	Operating Temperature [Max]	Operating Temperature [Min]	Size / Dimension [x]	Size / Dimension [y]	Size / Dimension [y]	Size / Dimension [x]	Size / Dimension [z]	Size / Dimension [z]	Voltage - Input (Max) [Max]	Current - Output (Max) [Max]	Applications	Voltage - Input (Min) [Min]	Standard Number	Package / Case	Power (Watts)	Number of Outputs	Voltage - Isolation	Voltage - Output 1	Mounting Type	Efficiency	Features	Voltage - Output 2
XP POWER JCD0548S09	Isolated Module	100 °C	-40 °C	1.25 "	0.8 in	20.3 mm	31.8 mm	10.4 mm	0.41 "	72 V	555 mA	ITE (Commercial)	36 V	62368-1	24-DIP Module 7 Leads	5 W	1	1.6 kV	9 V	Through Hole	84 %	OCP OVP SCP
XP POWER JCD0548D12	Isolated Module	100 °C	-40 °C	1.25 "	0.8 in	20.3 mm	31.8 mm	10.4 mm	0.41 "	72 V	208 mA	ITE (Commercial)	36 V	62368-1	24-DIP Module 8 Leads	5 W	2	1.6 kV	12 V	Through Hole	84 %	OCP OVP SCP	-12 V
XP POWER JCD0548D24	Isolated Module	100 °C	-40 °C	1.25 "	0.8 in	20.3 mm	31.8 mm	10.4 mm	0.41 "	72 V	104 mA	ITE (Commercial)	36 V	62368-1	24-DIP Module 8 Leads	5 W	2	1.6 kV	24 V	Through Hole	81 %	OCP OVP SCP	-24 V
XP POWER JCD0548D15	Isolated Module	100 °C	-40 °C	1.25 "	0.8 in	20.3 mm	31.8 mm	10.4 mm	0.41 "	72 V	167 mA	ITE (Commercial)	36 V	62368-1	24-DIP Module 8 Leads	5 W	2	1.6 kV	15 V	Through Hole	81 %	OCP OVP SCP	-15 V
XP POWER JCD0548S3V3	Isolated Module	100 °C	-40 °C	1.25 "	0.8 in	20.3 mm	31.8 mm	10.4 mm	0.41 "	72 V	1.3 A	ITE (Commercial)	36 V	62368-1	24-DIP Module 7 Leads	5 W	1	1.6 kV	3.3 V	Through Hole	76 %	OCP OVP SCP

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Isolated Module DC DC Converter 1 Output 3.3V 1.3A 36V - 72V Input
