796764-1

Active

TE Connectivity AMP Connectors

CONN RCPT MALE 4P SILVER SOLDER

Search across all available documentation for this part.

Active

TE Connectivity AMP Connectors

CONN RCPT MALE 4P SILVER SOLDER

Technical Specifications

Parameters and characteristics for this part

Specification	796764-1

Connector Type	Receptacle, Male Pins
Contact Finish - Mating	Silver
Contact Material	Brass
Material Flammability Rating	UL94 V-0
Mounting Feature	Flange
Mounting Type	Through Hole, Panel Mount
Number of Positions	4
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-55 °C
Orientation	A
Primary Material	Plastic
Shell Size - Insert	11-4
Termination	Solder
Voltage Rating	250 VAC

CONN RCPT MALE 4P SILVER SOLDER

Part	Orientation	Contact Finish - Mating	Voltage Rating	Mounting Type	Mounting Feature	Primary Material	Number of Positions	Material Flammability Rating	Connector Type	Shell Size - Insert	Operating Temperature [Max]	Operating Temperature [Min]	Contact Material	Termination
TE Connectivity AMP Connectors 796764-1	A	Silver	250 VAC	Panel Mount, Through Hole	Flange	Plastic	4	UL94 V-0	Male Pins, Receptacle	11-4	105 ░C	-55 °C	Brass	Solder

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

4 Position Circular Connector Receptacle, Male Pins Solder
