BB4505CNS

Active

TE Connectivity Raychem Cable Protection

WHIP,MC,CC,450-470MHZ TUN,5,BK,NGP,SPRIN

Search across all available documentation for this part.

Active

TE Connectivity Raychem Cable Protection

WHIP,MC,CC,450-470MHZ TUN,5,BK,NGP,SPRIN

Technical Specifications

Parameters and characteristics for this part

Part	Termination	Ingress Protection	Frequency Group [Max]	Frequency Group [Min]	Number of Bands	Frequency Range [Min]	Frequency Range [Max]	Frequency (Center/Band)	Gain	Antenna Type	Mounting Type	Power - Max [Max]	VSWR	Height (Max)	Height (Max) [Max]
TE Connectivity Raychem Cable Protection BB4505CR	NMO	IP67	1 GHz	300 MHz	1	450 MHz	470 MHz	460 MHz	5 dBi	Whip Straight	Base Mount
TE Connectivity Raychem Cable Protection BB4505CNS	NMO		1 GHz	300 MHz	1	450 MHz	470 MHz	460 MHz	5 dBi	Whip Straight	Base Mount	100 W	2	819.15 mm	32.25 in
TE Connectivity Raychem Cable Protection BB4505C	NMO		1 GHz	300 MHz	1	450 MHz	470 MHz	460 MHz	5 dBi	Whip Straight	Base Mount		2	939.8 mm	37 in
TE Connectivity Raychem Cable Protection BB4505CN	NMO		1 GHz	300 MHz	1	450 MHz	470 MHz	460 MHz	5 dBi	Whip Straight	Base Mount	100 W	2	819.15 mm	32.25 in

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

Whip Antenna, Single Band, UHF / Vehicular, External Mount, Stud/Screw/Lug Mount, NMO, Omnidirectional, Single Port, 3 < 6 dBi Peak Gain
