CA13639_G2-LAURA-SS-WAS-P
ActiveLEDiL
ASSEMBLY SQUARE 1 POS 21.6 X 21.6MM (D) / TAPE SHEET ROHS COMPLIANT: YES
Deep-Dive with AI
Search across all available documentation for this part.
CA13639_G2-LAURA-SS-WAS-P
ActiveLEDiL
ASSEMBLY SQUARE 1 POS 21.6 X 21.6MM (D) / TAPE SHEET ROHS COMPLIANT: YES
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | CA13639_G2-LAURA-SS-WAS-P |
|---|---|
| Color | Clear |
| For Use With/Related Manufacturer | Cree, Osram, Lumileds |
| Lens Size [x] | 21.6 mm |
| Lens Size [y] | 21.6 mm |
| Lens Style | Square with Flat Top |
| Material | Acrylic |
| Mounting Type | Adhesive Tape |
| Number of LEDs | 1 |
| Optical Pattern | Asymmetrical |
| Type | Lens With Holder |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
Description
General part information
CA13639 Series
Lens With Holder Clear Asymmetrical Adhesive Tape
