13SEEG3S

Active

Delta Electronics

PWR ENT RCPT IEC320-C14 PANEL QC

Search across all available documentation for this part.

Active

Delta Electronics

PWR ENT RCPT IEC320-C14 PANEL QC

Technical Specifications

Parameters and characteristics for this part

Specification	13SEEG3S

Accomodates a Fuse	False
Approval Agency	UL, VDE, CSA
Connector Style	IEC 320-C14
Connector Type	Male Blades, Receptacle
Current Rating - Appliance Inlet	13 A
Current Rating - Filter	13 A
Filter Type	Filtered (EMI, RFI) - Commercial
Mounting Type	Panel Mount, Flange
Panel Cutout Dimensions [x]	30.5 mm
Panel Cutout Dimensions [y]	21.2 mm
Termination	Quick Connect
Voltage Rating - Appliance Inlet [Max]	250 VAC
Voltage Rating - Appliance Inlet [Min]	115 VAC

PWR ENT RCPT IEC320-C14 PANEL QC

Part	Termination	Current Rating - Appliance Inlet	Connector Type	Mounting Type	Current Rating - Filter	Voltage Rating - Appliance Inlet [Min]	Voltage Rating - Appliance Inlet [Max]	Panel Cutout Dimensions [y]	Panel Cutout Dimensions [x]	Approval Agency	Accomodates a Fuse	Filter Type	Connector Style
Delta Electronics 13SEEG3S	Quick Connect	13 A	Male Blades, Receptacle	Flange, Panel Mount	13 A	115 VAC	250 VAC	21.2 mm	30.5 mm	CSA, UL, VDE		Filtered (EMI, RFI) - Commercial	IEC 320-C14

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

General part information

Power Entry Connector Receptacle, Male Blades IEC 320-C14 Panel Mount, Flange

Technical documentation and resources
