20HS21N471JC

Active

KEMET

CAP CER 470PF 2KV NP0 RADIAL

Search across all available documentation for this part.

Active

KEMET

CAP CER 470PF 2KV NP0 RADIAL

Technical Specifications

Parameters and characteristics commom to parts in this series

CAP CER 470PF 2KV NP0 RADIAL

Part	Temperature Coefficient	Operating Temperature [Min]	Operating Temperature [Max]	Voltage - Rated	Voltage - Rated	Height - Seated (Max) [Max] [z]	Height - Seated (Max) [Max] [z]	Capacitance	Mounting Type	Lead Spacing	Lead Spacing	Features	Lead Style	Tolerance	Applications	Package / Case	Size / Dimension [y]	Size / Dimension [x]
KEMET 20HS21N471JC	C0G, NP0	-55 °C	125 °C	2 kV	2000 V	7.11 mm	0.28 in	470 pF	Through Hole	5.59 mm	0.22 in	High Voltage	Straight	5 %	General Purpose	Radial	6.35 mm	0.32 in, 8.13 mm
KEMET 20HS21N221JC	C0G, NP0	-55 °C	125 °C	2 kV	2000 V	7.11 mm	0.28 in	220 pF	Through Hole	5.59 mm	0.22 in	High Voltage	Straight	5 %	General Purpose	Radial	6.35 mm	0.32 in, 8.13 mm
