GBP308
ActiveDiodes Inc
3A GLASS PASSIVATED BRIDGE RECTIFIER
Deep-Dive with AI
Search across all available documentation for this part.
GBP308
ActiveDiodes Inc
3A GLASS PASSIVATED BRIDGE RECTIFIER
Deep-Dive with AI
Technical Specifications
Parameters and characteristics for this part
| Specification | GBP308 |
|---|---|
| Current - Average Rectified (Io) | 3 A |
| Current - Reverse Leakage @ Vr | 5 µA |
| Diode Type | Single Phase |
| Mounting Type | Through Hole |
| Operating Temperature [Max] | 150 °C |
| Operating Temperature [Min] | -55 °C |
| Package / Case | GBP, 4-SIP |
| Supplier Device Package | GBP |
| Technology | Standard |
| Voltage - Forward (Vf) (Max) @ If | 1.05 V |
| Voltage - Peak Reverse (Max) [Max] | 800 V |
Pricing
Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly
| Distributor | Package | Quantity | $ | |
|---|---|---|---|---|
| Digikey | Tube | 1 | $ 0.95 | |
| 35 | $ 0.47 | |||
| 105 | $ 0.38 | |||
| 525 | $ 0.29 | |||
| 1015 | $ 0.27 | |||
| 2030 | $ 0.24 | |||
| 5005 | $ 0.22 | |||
| 10010 | $ 0.20 | |||
| 50015 | $ 0.19 | |||
Description
General part information
GBP308 Series
3A GLASS PASSIVATED BRIDGE RECTIFIER
