M12A-05PMMS-SH8001

Active

Amphenol LTW

CONN PLUG MALE 5P GOLD SLDR CUP

Search across all available documentation for this part.

Active

Amphenol LTW

CONN PLUG MALE 5P GOLD SLDR CUP

Technical Specifications

Parameters and characteristics for this part

Specification	M12A-05PMMS-SH8001

Color	Silver
Connector Type	Plug, Male Pins
Contact Finish - Mating	Gold
Contact Material	Copper Alloy
Current Rating (Amps)	4 A
Ingress Protection	IP68, IP69K
Insert Material	Polyamide (PA), Nylon, Glass Filled
Mounting Feature	Bulkhead - Rear Side Nut
Operating Temperature [Max]	105 ░C
Operating Temperature [Min]	-40 °C
Orientation	A
Primary Material	Metal
Shell Finish	Nickel
Shell Material	Zinc Alloy
Shell Size - Insert	M12-5
Shielding	Shielded
Voltage Rating	60 VAC

Part	Connector Type	Contact Finish - Mating	Orientation	Voltage Rating	Primary Material	Operating Temperature [Max]	Operating Temperature [Min]	Color	Insert Material	Shell Material	Shell Size - Insert	Shielding	Shell Finish	Mounting Feature	Current Rating (Amps)	Contact Material	Ingress Protection
Amphenol LTW M12A-05PMMS-SF8002	Male Pins Plug	Gold	A	60 VAC	Metal	85 °C	-40 °C	Silver	Polyamide (PA) Nylon Glass Filled	Zinc Alloy	M12-5	Shielded	Nickel	Bulkhead - Front Side Nut	4 A	Copper Alloy	IP68 IP69K
Amphenol LTW M12A-05PMMS-SH8001	Male Pins Plug	Gold	A	60 VAC	Metal	105 ░C	-40 °C	Silver	Polyamide (PA) Nylon Glass Filled	Zinc Alloy	M12-5	Shielded	Nickel	Bulkhead - Rear Side Nut	4 A	Copper Alloy	IP68 IP69K

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

5 Position Circular Connector Plug, Male Pins Solder Cup
