AXE170527A

Obsolete

Panasonic Electric Works

CONN SOCKET 70POS SMD GOLD

Search across all available documentation for this part.

Obsolete

Panasonic Electric Works

CONN SOCKET 70POS SMD GOLD

Technical Specifications

Parameters and characteristics for this part

Specification	AXE170527A

Connector Type	Socket, Center Strip Contacts
Contact Finish	Gold
Features	Solder Retention
Height Above Board [z]	0.03 in
Height Above Board [z]	0.75 mm
Mated Stacking Heights	0.8 mm
Mounting Type	Surface Mount
Number of Positions	70
Number of Rows	2
Pitch [x]	0.016 in
Pitch [x]	0.4 mm

Part	Features	Mounting Type	Mated Stacking Heights	Connector Type	Number of Positions	Height Above Board [z]	Height Above Board [z]	Number of Rows	Contact Finish	Pitch [x]	Pitch [x]
Panasonic Electric Works AXE170527A	Solder Retention	Surface Mount	0.8 mm	Socket Center Strip Contacts	70	0.03 in	0.75 mm	2	Gold	0.016 in	0.4 mm
Panasonic Electric Works AXE170124	Solder Retention	Surface Mount	0.8 mm	Socket Center Strip Contacts	70	0.03 in	0.75 mm	2	Gold	0.016 in	0.4 mm

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

General part information

70 Position Connector Socket, Center Strip Contacts Surface Mount Gold
