General part information
Circular Push Pull Connectors STRAIGHT PLUG MALE W. CABLE COLLET
Technical documentation and resources
Parameters and characteristics commom to parts in this series
| Specification | FHG.0K.307.CLAC45Z | 0K Series |
|---|---|---|
| Backshell Material, Plating | Brass, Chrome | Brass, Chrome, Black Chrome |
| Cable Opening | - | 0.142 - 0.157 in |
| Cable Opening | - | 4 mm |
| Cable Opening | - | 3.6 mm |
| Cable Opening [Max] [diameter] | 0.177 in | 0.177 - 0.197 in |
| Cable Opening [Max] [diameter] | 4.5 mm | 4.5 - 5 mm |
| Cable Opening [Min] [diameter] | 4.1 mm | 4.1 - 4.6 mm |
| Cable Opening [Min] [diameter] | 0.161 in | 0.161 - 0.181 in |
| Color | Silver | Silver, Black |
| Connector Type | Plug, Male Pins | Plug, Male Pins, Receptacle, Female Sockets |
| Contact Finish - Mating | Gold | Gold |
| Contact Finish Thickness - Mating | 1 µm | 1 - 1.5 µm |
| Contact Finish Thickness - Mating | 39.4 µin | 39.4 - 59 µin |
| Contact Material | Brass | Brass, Bronze |
| Current Rating (Amps) | 2.5 A | 2.5 - 10 A |
| Fastening Type | Push-Pull | Push-Pull |
| Features | Backshell | Backshell |
| Ingress Protection | IP66/IP68 | IP66/IP68 |
| Insert Material | Polyetheretherketone (PEEK) | Polyetheretherketone (PEEK) |
| Material Flammability Rating | UL94 V-0 | UL94 V-0 |
| Mounting Type | Free Hanging (In-Line), Right Angle | Free Hanging (In-Line), Right Angle |
| Number of Positions | 7 | 2 - 7 |
| Operating Temperature [Max] | 200 °C | 200 °C |
| Operating Temperature [Min] | -55 °C | -55 °C |
| Orientation | G | G |
| Primary Material | Metal | Metal |
| Shell Finish | Chrome | Chrome |
| Shell Material | Brass | Brass |
| Shell Size - Insert | 307 | 302 - 307 |
| Shielding | Shielded | Shielded |
| Termination | - | Crimp |
Circular Push Pull Connectors STRAIGHT PLUG MALE W. CABLE COLLET
| Part | Shielding | Primary Material | Features | Contact Finish - Mating | Contact Finish Thickness - Mating | Contact Finish Thickness - Mating | Shell Finish | Backshell Material, Plating | Color | Insert Material | Current Rating (Amps) | Ingress Protection | Shell Material | Contact Material | Fastening Type | Mounting Type | Material Flammability Rating | Orientation | Shell Size - Insert | Cable Opening [Max] [diameter] | Cable Opening [Min] [diameter] | Cable Opening [Min] [diameter] | Cable Opening [Max] [diameter] | Connector Type | Operating Temperature [Min] | Operating Temperature [Max] | Number of Positions | Cable Opening [custom] | Cable Opening [custom] | Cable Opening [custom] | Termination |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
Shielded | Metal | Backshell | Gold | 1 µm | 39.4 µin | Chrome | Brass, Chrome | Silver | Polyetheretherketone (PEEK) | 6.5 A | IP66/IP68 | Brass | Brass | Push-Pull | Free Hanging (In-Line) | UL94 V-0 | G | 305 | 0.177 in | 4.1 mm | 0.161 in | 4.5 mm | Male Pins, Plug | -55 °C | 200 °C | ||||||
Shielded | Metal | Backshell | Gold | 1 µm | 39.4 µin | Black Chrome, Brass | Black | Polyetheretherketone (PEEK) | 10 A | IP66/IP68 | Brass | Brass | Push-Pull | Free Hanging (In-Line) | UL94 V-0 | G | 302 | Male Pins, Plug | -55 °C | 200 °C | 2 | 0.142 in, 0.157 in | 4 mm | 3.6 mm | |||||||
Shielded | Metal | Backshell | Gold | 1 µm | 39.4 µin | Chrome | Brass, Chrome | Silver | Polyetheretherketone (PEEK) | 10 A | IP66/IP68 | Brass | Brass | Push-Pull | Free Hanging (In-Line) | UL94 V-0 | G | 302 | Male Pins, Plug | -55 °C | 200 °C | 2 | 0.142 in, 0.157 in | 4 mm | 3.6 mm | Crimp | |||||
Shielded | Metal | Backshell | Gold | 1 µm | 39.4 µin | Chrome | Brass, Chrome | Silver | Polyetheretherketone (PEEK) | 10 A | IP66/IP68 | Brass | Brass | Push-Pull | Free Hanging (In-Line) | UL94 V-0 | G | 302 | 0.197 in | 4.6 mm | 0.181 in | 5 mm | Male Pins, Plug | -55 °C | 200 °C | 2 | |||||
Shielded | Metal | Backshell | Gold | 1 µm | 39.4 µin | Chrome | Brass, Chrome | Silver | Polyetheretherketone (PEEK) | 2.5 A | IP66/IP68 | Brass | Brass | Push-Pull | Free Hanging (In-Line), Right Angle | UL94 V-0 | G | 307 | 0.177 in | 4.1 mm | 0.161 in | 4.5 mm | Male Pins, Plug | -55 °C | 200 °C | 7 | |||||
Shielded | Metal | Backshell | Gold | 1.5 Ám | 59 Áin | Chrome | Brass, Chrome | Silver | Polyetheretherketone (PEEK) | 7 A | IP66/IP68 | Brass | Bronze | Push-Pull | Free Hanging (In-Line) | UL94 V-0 | G | 304 | 0.197 in | 4.6 mm | 0.181 in | 5 mm | Receptacle, Female Sockets | -55 °C | 200 °C | 4 | |||||
Shielded | Metal | Backshell | Gold | 1 µm | 39.4 µin | Chrome | Brass, Chrome | Silver | Polyetheretherketone (PEEK) | 7 A | IP66/IP68 | Brass | Brass | Push-Pull | Free Hanging (In-Line) | UL94 V-0 | G | 304 | 0.197 in | 4.6 mm | 0.181 in | 5 mm | Male Pins, Plug | -55 °C | 200 °C | 4 | Crimp |
