1733068

Active

Phoenix Contact

PLUGGABLE TERMINAL BLOCKS 13 POS 5MM PITCH PLUG 24-16AWG SPRING

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	50	$ 14.51
Sager	N/A	50	$ 17.07
		100	$ 16.47

Description

General part information

FKCN Series

Pluggable Terminal Blocks 13 Pos 5mm pitch Plug 24-16AWG Spring

Documents

Technical documentation and resources

Datasheet

Document

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	1733068	FKCN Series

Color	Green	Green
Contact Mating Finish	Tin	Tin
Current - IEC	12 A	12 A
Current - UL	-	10 A
Features	Retention Latches (Non-Wire Side), Mating Flange	Retention Latches (Non-Wire Side), Mating Flange
Housing Material	Polybutylene Terephthalate (PBT)	Polybutylene Terephthalate (PBT), Polyamide (PA), Nylon
Insulation Height	0.429 in	0.429 in
Insulation Height	10.9 mm	10.9 mm
Material Flammability Rating	UL94 V-0	UL94 V-0
Mounting Type	Free Hanging (In-Line)	Free Hanging (In-Line)
Number of Levels	1	1
Number of Positions	13	4 - 18
Pitch [x]	5 mm	5 - 5.08 mm
Pitch [x]	0.197 in	0.197 - 0.2 in
Positions Per Level	13	4 - 18
Termination Style	Screwless - Push-In Spring	Screwless - Push-In Spring, Push-In Spring, Screwless - Leg Spring
Type	Plug, Female Sockets	Plug, Female Sockets
Voltage - IEC	630 V	630 V
Voltage - UL	-	300 V
Wire Gauge or Range - AWG [Max]	24 AWG	24 AWG
Wire Gauge or Range - AWG [Min]	16 AWG	14 - 16 AWG
Wire Gauge or Range - mm˛ [Max]	1.5 mm˛	1.5 mm˛
Wire Gauge or Range - mm˛ [Min]	0.2 mm˛	0.2 mm˛
Wire Gauge or Range - mm²	-	0.2 mm²
Wire Gauge or Range - mm²	-	1.5 mm²
Wire Strip Length	10 mm	10 mm

FKCN Series

Pluggable Terminal Blocks 13 Pos 5mm pitch Plug 24-16AWG Spring

Part	Mounting Type	Current - IEC	Type	Wire Gauge or Range - AWG [Max]	Wire Gauge or Range - AWG [Min]	Positions Per Level	Color	Wire Gauge or Range - mm˛ [Min]	Wire Gauge or Range - mm˛ [Max]	Wire Strip Length	Housing Material	Material Flammability Rating	Contact Mating Finish	Voltage - IEC	Insulation Height	Insulation Height	Number of Levels	Termination Style	Pitch [x]	Pitch [x]	Number of Positions	Voltage - UL	Wire Gauge or Range - mm² [Min]	Wire Gauge or Range - mm² [Max]	Current - UL	Features
Phoenix Contact 1732894	Free Hanging (In-Line)	12 A	Plug, Female Sockets	24 AWG	16 AWG	18	Green	0.2 mm˛	1.5 mm˛	10 mm	Polybutylene Terephthalate (PBT)	UL94 V-0	Tin	630 V	0.429 in	10.9 mm	1	Screwless - Push-In Spring	5 mm	0.197 in	18
Phoenix Contact 1754681	Free Hanging (In-Line)	12 A	Plug, Female Sockets	24 AWG	14 AWG	14	Green			10 mm	Polyamide (PA), Nylon	UL94 V-0	Tin	630 V	0.429 in	10.9 mm	1	Push-In Spring, Screwless - Leg Spring	5.08 mm	0.2 in	14	300 V	0.2 mm²	1.5 mm²	10 A
Phoenix Contact 1732797	Free Hanging (In-Line)	12 A	Plug, Female Sockets	24 AWG	16 AWG	7	Green			10 mm	Polybutylene Terephthalate (PBT)	UL94 V-0	Tin	630 V	0.429 in	10.9 mm	1	Screwless - Push-In Spring	5 mm	0.197 in	7		0.2 mm²	1.5 mm²
Phoenix Contact 1733068	Free Hanging (In-Line)	12 A	Plug, Female Sockets	24 AWG	16 AWG	13	Green	0.2 mm˛	1.5 mm˛	10 mm	Polybutylene Terephthalate (PBT)	UL94 V-0	Tin	630 V	0.429 in	10.9 mm	1	Screwless - Push-In Spring	5 mm	0.197 in	13					Mating Flange, Retention Latches (Non-Wire Side)
Phoenix Contact 1732988	Free Hanging (In-Line)	12 A	Plug, Female Sockets	24 AWG	16 AWG	4	Green	0.2 mm˛	1.5 mm˛	10 mm	Polybutylene Terephthalate (PBT)	UL94 V-0	Tin	630 V	0.429 in	10.9 mm	1	Screwless - Push-In Spring	5 mm	0.197 in	4					Mating Flange, Retention Latches (Non-Wire Side)
