011032CD075

Active

Essentra Components

BINDER COMBINATION SCREW 10-32 T

Deep-Dive with AI

Search across all available documentation for this part.

DocumentsDatasheet

011032CD075

Active

Essentra Components

BINDER COMBINATION SCREW 10-32 T

Deep-Dive with AI

DocumentsDatasheet

Specifications Pricing Series Description Documents

Technical Specifications

Parameters and characteristics commom to parts in this series

Specification	011032CD075	011032CD Series

Drive Type	Combination	Combination
Head Diameter	-	0.389 "
Head Diameter	-	9.87 mm
Head Height	-	5.97 mm
Head Height	-	0.235 "
Length - Below Head	0.75 "	0.125 - 22.23 "
Length - Below Head	19.05 mm	0.875 - 38.1 mm
Length - Below Head	0.75 "	0.125 - 1 "
Length - Below Head	-	0.188 - 2 in
Length - Below Head	-	1/2
Length - Below Head	-	7.94 - 11.11 mm
Length - Below Head	-	0.313 - 0.438 in
Length - Below Head	-	4.76 - 50.8 mm
Length - Overall [x]	25.02 mm	9.14 - 56.77 mm
Length - Overall [x]	0.985 in	0.36 - 2.235 in
Material	Nylon	Nylon
Screw Head Type	Binding Head	Binding Head
Thread Size	#10-32	#10-32
Type	Machine Screw	Machine Screw

011032CD Series

MACH SCREW BINDING COMBO #10-32

Part	Type	Head Diameter [diameter]	Head Diameter [diameter]	Thread Size	Head Height [z]	Head Height [z]	Material	Length - Below Head [x]	Length - Below Head	Drive Type	Screw Head Type	Length - Overall [x]	Length - Overall [x]	Length - Below Head	Length - Below Head	Length - Below Head	Length - Below Head [custom]	Length - Below Head [custom]	Length - Below Head [x]
Essentra Components 011032CD150	Machine Screw	0.389 "	9.87 mm	#10-32	5.97 mm	0.235 "	Nylon	1.5 in	38.1 mm	Combination	Binding Head	44.07 mm	1.735 in
Essentra Components 011032CD075	Machine Screw			#10-32			Nylon		19.05 mm	Combination	Binding Head	25.02 mm	0.985 in	0.75 "	0.75 "
Essentra Components 011032CD012	Machine Screw			#10-32			Nylon		3.18 mm	Combination	Binding Head	9.14 mm	0.36 "	0.125 in	0.125 in
Essentra Components 011032CD050	Machine Screw			#10-32			Nylon		12.7 mm	Combination	Binding Head	18.67 mm	0.735 "		0.5 in	1/2
Essentra Components 011032CD031	Machine Screw	0.389 "	9.87 mm	#10-32	5.97 mm	0.235 "	Nylon			Combination	Binding Head						7.94 mm	0.313 in
Essentra Components 011032CD100	Machine Screw			#10-32			Nylon		25.4 mm	Combination	Binding Head				1 in
Essentra Components 011032CD062	Machine Screw	0.389 "	9.87 mm	#10-32	5.97 mm	0.235 "	Nylon		15.88 mm	Combination	Binding Head	21.84 mm	0.86 "	0.625 in	0.625 in
Essentra Components 011032CD087	Machine Screw	0.389 "	9.87 mm	#10-32	5.97 mm	0.235 "	Nylon	0.875 in	0.875 in	Combination	Binding Head			22.23 mm
Essentra Components 011032CD018	Machine Screw	0.389 "	9.87 mm	#10-32	5.97 mm	0.235 "	Nylon	0.188 in		Combination	Binding Head	10.73 mm	0.423 in						4.76 mm
Essentra Components 011032CD043	Machine Screw	0.389 "	9.87 mm	#10-32	5.97 mm	0.235 "	Nylon			Combination	Binding Head						11.11 mm	0.438 in

Pricing

Prices provided here are for design reference only. For realtime values and availability, please visit the distributors directly

Distributor	Package	Quantity	$

Digikey	Bulk	1	$ 0.10
		5	$ 0.08
		10	$ 0.07
		25	$ 0.06
		50	$ 0.05
		100	$ 0.05
		250	$ 0.04
		500	$ 0.04
		1000	$ 0.04

Description

General part information

011032CD Series

#10-32 Binding Head Machine Screw Combination Drive Nylon

Documents

Technical documentation and resources
